Availability:
1 in stock
Super-precision angular contact ball bearing, 25° contact angle, phenolic outer-ring centred cage, ABEC 7, medium preload, universally matchable pair.
List Price
$171.50
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNR |
|---|---|
| MPN | 7009HG1DUJ84 |
| Model | 7009A5/ACD 7009E T DUM P4 / 3MM9109WI CR DUM / 7009 H G1 DU J84 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 45 mm |
| OD | 75 mm |
| Width | 16 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Base Number | 7009 |
| Mpn Variants | 7009HG1DUJ84 / 7009-H-G1-DU-J84 / 7009 H G1 DU J84 / 7009A5/ACD |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Part Number | 7009HG1DUJ84 |
NTN-SNR 7009HG1DUJ84 super-precision angular contact ball bearing, ISO 70 dimension series, supplied as a universally matchable set of two. Contact Angle: 25°. Number Of Rows: 1. Rolling Elements: Ball. Bearing Material: Bearing steel. Closure Type: Open. Bore Type: Straight. Series: ISO 70.
7009 gives the ISO 70 dimension series. H sets the Contact Angle: 25°. G1 gives the cage — Cage Material: Phenolic (laminated resin), Cage Type: Machined, outer-ring centred. J84 sets Preload: Medium and Precision Class: ISO Class 4 (ABEC 7 / P4). Searchable forms of the number: 7009HG1DUJ84, 7009-H-G1-DU-J84, 7009 H G1 DU J84.
A 25° contact angle carries more thrust and less speed than a 15° angle, which suits machine-tool spindles and ball-screw ends working against a steady axial load. Cage Material: Phenolic (laminated resin) runs light and quiet at high speed and takes oil-mist and oil-air lubrication. Cage Type: Machined, outer-ring centred holds the cage stable on the outer-ring land at speed. Precision Class: ISO Class 4 (ABEC 7 / P4) holds running accuracy close, giving low radial and axial runout. Preload: Medium fixes the axial stiffness of the mounted set. Internal Clearance: N/A — a preloaded set is stiffness-set rather than clearance-set.
Unit Quantity: 2 Pcs, a factory-matched pair. Mounting Arrangement: Universal (DB, DF or DT). The pair stacks back-to-back, face-to-face or in tandem and reaches the same preload in any of the three.
Carton cross-designations: SNR 7009A5/ACD, FAG 7009E-T-DUM-P4, Fafnir 3MM9109WI CR DUM. Each carries a 25° contact angle and a universally matchable medium-preload execution. A 7009C or B7009-C execution is a 15° part and is a related design rather than a substitution.
$231.30
29 in stock
