SNFA VEX25-9CE0DUL high-speed angular contact ball bearing pair, 25 x 47 x 12 mm, 12° contact angle, ABEC 9 / P2, light preload, open. Two bearings.
List Price
$145.30
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | VEX25-9CE0DUL |
| Model | VEX25-9CE0DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 25 mm |
| OD | 47 mm |
| Width | 12 mm |
| Series | SNFA VEX (ISO 10) |
|---|---|
| Preload | Light (L) |
| Cage Type | Machined, outer-ring located |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 12° |
| Base Number | 7005 |
| Overall Width | 12 mm |
| Mpn Variants | VEX25-9CE0DUL, VEX25-9-CE-0-DUL, VEX25 9 CE 0 DUL, 7005-P2, 7005 C T P2 DUL, 2MMV9105 WI CR DUL |
| Arrangement Configuration | Duplex universal pair (DU) |
| Precision Class | ABEC 9 / P2 |
| Additional Attributes | Minimum chamfer Rmin 0.6 mm; rmin 0.3 mm |
SNFA VEX25-9CE0DUL is a duplex universal pair of high-speed super-precision angular contact ball bearings, SNFA VEX series, ISO dimension series 10, size 7005. Bore Diameter: 25 mm. Outside Diameter: 47 mm. Overall Width: 12 mm. Contact Angle: 12°. Precision Class: ABEC 9 / P2. Preload: Light.
VEX — SNFA high-speed series, ISO dimension series 10.
25 — bore diameter, 25 mm.
9 — ABEC 9 precision.
C — stratified textile resin (phenolic) cage.
E — cage located on the outer ring.
0 — 12° nominal contact angle.
DU — duplex universal. The pair mounts back-to-back, face-to-face or tandem.
L — light preload.
The 12° angle is the lowest in the SNFA range and favours speed and radial stiffness. ABEC 9 is the tightest SNFA running-accuracy grade. Cage Material: Phenolic. Cage Type: Machined, outer-ring located.
Minimum chamfer, outer ring (Rmin): 0.6 mm. Minimum chamfer, inner ring (rmin): 0.3 mm. Bore Type: Straight. Closure Type: Open. Snap Ring: No.
Unit Quantity: 2 Pcs. A universally matched pair with light preload.
ISO size 7005, 25 x 47 x 12 mm. Other makers list this envelope at 15° and 25°; the 12° angle is specific to SNFA.
