Availability:
1 in stock
Super-precision angular contact ball bearing pair, 95 x 145 x 24 mm, 15° contact angle, ABEC 7 / P4, light preload. SKF 7019 CD/P4ADGA equivalent.
List Price
$756.53
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | EX95-7CE1DUL |
| Model | 2MM-9119 DUL / 7019C P4 DUL / EX95-7-CE-1-DUL |
| Bearing Type | Angular Contact Ball Bearing |
| ID | 95 mm |
| OD | 145 mm |
| Width | 24 mm |
| Mpn Variants | EX95-7CE1DUL, EX 95 7CE1 DUL, EX-95-7-CE-1-DUL, EX95 7 CE 1 DUL |
|---|---|
| Precision Class | ABEC 7 / P4 |
| Cage Type | Outer-ring guided |
| Dynamic Load Rating | 81,900 N |
| Static Load Rating | 80,000 N |
| Series | EX (ISO 10) |
| Item Weight | 1.19 kg (2.62 lb) |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Snap Ring Included | No |
| Limiting Speed | 8,500 rpm grease; 14,000 rpm oil |
| Contact Angle | 15° |
| Preload | Light |
| Mounting Arrangement | Universal matched pair (back-to-back, face-to-face or tandem) |
| Cross Reference 1 | SKF 7019 CD/P4ADGA |
|---|---|
| Cross Reference 2 | SKF 7019 CDGA/P4A |
| Cross Reference 3 | FAG B7019-C-T-P4S-UL |
| Cross Reference 4 | NSK 7019CTRDULP4 |
| Cross Reference 5 | Fafnir 2MM9119WICRDUL |
SNFA EX95-7CE1DUL is a matched set of two super-precision single-row angular contact ball bearings from the SNFA EX high-capacity series, ISO dimension series 10. Bore Diameter: 95 mm. Outside Diameter: 145 mm. Width: 24 mm per bearing. Contact Angle: 15°. Precision Class: ABEC 7 / P4. The current SKF equivalent is the 7019 CD/P4ADGA high-capacity D design pair.
EX — SNFA high-capacity angular contact series, ISO dimension series 10 (70xx envelope).
95 — bore diameter in millimetres.
7 — SNFA precision grade, ABEC 7 (ISO P4).
C — phenolic resin cage.
E — cage centred on the outer ring.
1 — 15° contact angle.
DU — universal duplex set: two bearings ground for back-to-back, face-to-face or tandem mounting.
L — light preload.
Dynamic Load Rating: 81,900 N per bearing. Static Load Rating: 80,000 N per bearing. Limiting Speed: 8,500 rpm grease; 14,000 rpm oil-air, single bearing. The 15° angle favours radial stiffness and speed; light preload keeps heat generation low.
Item Weight: 1.19 kg (2.62 lb) per bearing. Cage Type: Outer-ring guided. Cage Material: Phenolic. Closure Type: Open.
Unit Quantity: 2 Pcs. Mounting Arrangement: Universal matched pair, back-to-back, face-to-face or tandem. Preload: Light.
SKF owns SNFA and lists the EX series as the SNFA equivalent of its 70 .. CD range. Cross-references with the same 95 x 145 x 24 mm envelope and 15° contact angle: SKF 7019 CD/P4ADGA, SKF 7019 CDGA/P4A, FAG B7019-C-T-P4S-UL, NSK 7019CTRDULP4, Fafnir 2MM9119WICRDUL.
