SKF7022 ACDGA/P4AAngular Contact Ball Bearing — Super-Precision, 110 mm ID, 170 mm OD, 28 mm Width, 25° Contact Angle, Extra Light Preload, P4A

Condition: New

Availability:

1 in stock

SKF 7022 ACDGA/P4A super-precision angular contact ball bearing, 110 x 170 x 28 mm, 25° contact angle, P4A, extra light preload, 104,000 N dynamic.

Same day shipment

List Price

$1,140.99

1 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

1 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandSKF
MPN7022 ACDGA/P4A
Model7022ACDGA/P4A
Bearing TypeAngular Contact Ball Bearing, Open
ID110 mm
OD170 mm
Width28 mm

Technical Specifications

MaterialSteel
Series7000
PreloadExtra light (GA)
Mpn Variants7022 ACDGA/P4A, 7022ACDGAP4A, 7022-ACDGA-P4A, 7022-ACDGA/P4A
Precision ClassP4A (ABEC 7 / P4 dimensional)
Dynamic Load Rating104,000 N
Static Load Rating104,000 N
Precision RatingP4A (ABEC 7 / P4 dimensional)
Rolling ElementsBall
Item Weight1.93 kg (4.25 lb) per bearing
Number Of Rows1
Bore TypeStraight
Snap Ring IncludedNo
Harmonization Code8482.10.50
Contact Angle25°
Mounting ArrangementUniversal: back-to-back, face-to-face or tandem
Bearing MaterialBearing steel
Closure TypeOpen

Cross-References

Cross Reference 1FAG B7022-E-T-P4S
Cross Reference 2NSK 7022A5
Cross Reference 3Fafnir 3MM9122WI
Cross Reference 4SNFA VEX 110 7CE3
Seller Part Number: B-BR1#DMQ8LB

Product Description

What this part is:

SKF 7022 ACDGA/P4A is a super-precision, high-capacity single row angular contact ball bearing in the 70 series, with a 25° contact angle and extra light preload for universal matching. Bore Diameter: 110 mm. Outside Diameter: 170 mm. Width: 28 mm. It carries combined radial and one-direction axial load in machine tool spindles.

Decoding the designation:

70 — ISO dimension series 10, light section.

22 — bore code, 22 x 5 = 110 mm bore.

ACD — 25° contact angle, high-capacity D design.

GA — single bearing for universal matching, extra light preload. Any two GA bearings mount back-to-back, face-to-face or in tandem.

P4A — SKF tolerance class: ISO P4 dimensional accuracy with ISO P2 running accuracy.

Specifications:

Bore Diameter: 110 mm. Outside Diameter: 170 mm. Width: 28 mm. Contact Angle: 25°. Dynamic Load Rating: 104,000 N. Static Load Rating: 104,000 N. Preload: Extra light (GA). Precision Class: P4A (ABEC 7 / P4 dimensional, P2 running accuracy). Number Of Rows: 1. Contact Type: Normal two-point contact. Design: High-capacity D. Bearing Material: Bearing steel. Closure Type: Open. Item Weight: 1.93 kg (4.25 lb) per bearing. Harmonization Code: 8482.10.50.

Dimensions and mounting:

Mounting Arrangement: universal, back-to-back, face-to-face or tandem with any other 7022 ACDGA bearing.

Compatibility and replacement:

Cross-references: FAG B7022-E-T-P4S, NSK 7022A5, Fafnir 3MM9122WI and SNFA VEX 110 7CE3, all in the 110 x 170 x 28 mm envelope at 25°. MPN variants: 7022 ACDGA/P4A, 7022ACDGAP4A, 7022-ACDGA-P4A, 7022-ACDGA/P4A.

Frequently asked questions:

What size is the SKF 7022 ACDGA/P4A?

Bore Diameter: 110 mm. Outside Diameter: 170 mm. Width: 28 mm.

What do ACD and GA mean in 7022 ACDGA/P4A?

ACD is a 25° contact angle in the high-capacity D design. GA is a single bearing for universal matching with extra light preload.

What are the load ratings of the 7022 ACDGA/P4A?

Dynamic Load Rating: 104,000 N. Static Load Rating: 104,000 N.
