Availability:
1 in stock
Super-precision angular contact ball bearing, 35 x 72 x 17 mm, 25° contact angle, ABEC 7 / P4, universal single, light preload. SKF 7207 ACDGA/P4A equivalent.
List Price
$107.08
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | E235-7CE3UL |
| Model | 3MM-207 WI / 7207-A P4 / E 235-7 CE 3 U L |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 35 mm |
| OD | 72 mm |
| Width | 17 mm |
| Material | Bearing Steel |
|---|---|
| Series | E 200 (ISO 02) |
| Preload | Light |
| Mpn Variants | E235-7CE3UL, E 235 7CE3 UL, E-235-7-CE-3-UL, E 235-7 CE 3 U L |
| Precision Class | ABEC 7 / P4 |
| Cage Type | Outer-ring guided |
| Dynamic Load Rating | 30,700 N |
| Static Load Rating | 20,800 N |
| Rolling Elements | Ball |
| Item Weight | 0.282 kg (0.62 lb) |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 18,000 rpm grease; 30,000 rpm oil |
| Harmonization Code | 8482.10.50.68 |
| Contact Angle | 25° |
| Mounting Arrangement | Universally ground single bearing (back-to-back, face-to-face or tandem) |
| Cross Reference 1 | SKF 7207 ACDGA/P4A |
|---|---|
| Cross Reference 2 | SKF 7207 ACD/P4A |
| Cross Reference 3 | NSK 7207A5TYNSULP4 |
| Cross Reference 4 | FAG B7207-E-T-P4S-UL |
| Cross Reference 5 | Fafnir 3MM207WICRSUL |
SNFA E235-7CE3UL is a single universally matchable super-precision angular contact ball bearing from the SNFA E 200 series, ISO dimension series 02. Bore Diameter: 35 mm. Outside Diameter: 72 mm. Width: 17 mm. Contact Angle: 25°. Precision Class: ABEC 7 / P4. The current SKF equivalent is the 7207 ACDGA/P4A high-capacity D design.
E2 — SNFA E 200 series, ISO dimension series 02 (72xx envelope).
35 — bore diameter in millimetres.
7 — SNFA precision grade, ABEC 7 (ISO P4).
C — phenolic resin cage.
E — cage centred on the outer ring.
3 — 25° contact angle.
U — universal single bearing, ground to pair back-to-back, face-to-face or in tandem with any other U bearing of the same size and preload.
L — light preload when paired.
Dynamic Load Rating: 30,700 N. Static Load Rating: 20,800 N. Limiting Speed: 18,000 rpm grease; 30,000 rpm oil-air. The 25° angle carries axial load in addition to radial load.
Item Weight: 0.282 kg (0.62 lb). Cage Type: Outer-ring guided. Cage Material: Phenolic. Closure Type: Open.
Unit Quantity: 1 Pc. Mounting Arrangement: Universally ground single bearing. Preload: Light.
SKF owns SNFA and lists the E 200 series as the SNFA equivalent of its 72 .. D range. Cross-references with the same 35 x 72 x 17 mm envelope and 25° contact angle: SKF 7207 ACDGA/P4A, SKF 7207 ACD/P4A, NSK 7207A5TYNSULP4, FAG B7207-E-T-P4S-UL, Fafnir 3MM207WICRSUL.
