Super-precision angular contact ball bearing pair, 17 x 35 x 10 mm, 15° contact angle, ABEC 7 / P4, light preload. Compare SKF 7003 CD/P4ADGB.
List Price
$166.10
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| Model | EX17 7 CE 1 DUL / 7003 C T P4 DUL / 2MM9103 WI CR DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 17 mm |
| OD | 35 mm |
| Width | 10 mm |
| Material | Bearing Steel |
|---|---|
| Series | EX (ISO 10) |
| Condition | New |
| Preload | Light |
| Mpn Variants | EX17-7CE1DUL, EX 17 7CE1 DUL, EX17-7-CE-1-DUL, EX17 7 CE 1 DUL |
| Precision Class | ABEC 7 / P4 |
| Cage Type | Outer-ring guided |
| Dynamic Load Rating | 6,760 N |
| Static Load Rating | 3,250 N |
| Rolling Elements | Ball |
| Item Weight | 0.037 kg (0.08 lb) |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 50,000 rpm grease; 75,000 rpm oil |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal matched pair (back-to-back, face-to-face or tandem) |
| Cross Reference 1 | NSK 7003CTRDULP4 – 15°, phenolic cage, light preload |
|---|---|
| Cross Reference 2 | FAG B7003-C-T-P4S-UL – 15°, phenolic, light preload |
| Cross Reference 3 | Fafnir 2MM9103WICRDUL – 15°, phenolic, light preload |
| Cross Reference 4 | SKF 7003 CD/P4ADGB – 15°, light preload; check cage |
SNFA EX17-7CE1DUL is a matched set of two super-precision single-row angular contact ball bearings from the SNFA EX high-capacity series, ISO dimension series 10. Bore Diameter: 17 mm. Outside Diameter: 35 mm. Width: 10 mm per bearing. Contact Angle: 15°. Precision Class: ABEC 7 / P4. The nearest current SKF number is the 7003 CD/P4ADGB high-capacity D design pair at light preload.
EX — SNFA high-capacity angular contact series, ISO dimension series 10 (70xx envelope).
17 — bore diameter in millimetres.
7 — SNFA precision grade, ABEC 7 (ISO P4).
C — phenolic resin cage.
E — cage centred on the outer ring.
1 — 15° contact angle.
DU — universal duplex set: two bearings ground for back-to-back, face-to-face or tandem mounting.
L — light preload.
Dynamic Load Rating: 6,760 N per bearing. Static Load Rating: 3,250 N per bearing. Limiting Speed: 50,000 rpm grease; 75,000 rpm oil-air, single bearing. The 15° angle favours radial stiffness and speed; light preload keeps heat generation low.
Item Weight: 0.037 kg (0.08 lb) per bearing. Cage Type: Outer-ring guided. Cage Material: Phenolic. Closure Type: Open.
Unit Quantity: 2 Pcs. Mounting Arrangement: Universal matched pair, back-to-back, face-to-face or tandem. Preload: Light.
SKF owns SNFA, and the EX series sits alongside SKF’s 70 .. CD range. Other makers’ 15°, light-preload numbers in 17 x 35 x 10 mm: NSK 7003CTRDULP4, FAG B7003-C-T-P4S-UL, Fafnir 2MM9103WICRDUL and SKF 7003 CD/P4ADGB.
