SNFA E295-7CE3DUL-1/2PR angular contact ball bearing, 95 x 170 x 32 mm, 25° contact angle, ABEC 7 / P4, light preload, duplex universal. One bearing.
List Price
$665.53
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | E295-7CE3DUL-1/2PR |
| Model | E295-7CE3DUL |
| Bearing Type | Angular Contact Ball Bearing |
| ID | 95 mm |
| OD | 170 mm |
| Width | 32 mm |
| Dynamic Load Rating | 11,190 daN (C33) |
|---|---|
| Static Load Rating | 12,800 daN (C0) |
| Base Number | 7219 |
| Overall Width | 32 mm |
| Mpn Variants | E295-7CE3DUL-1/2PR, E295-7CE3DUL, E-295-7-CE-3-DUL, E 295-7 CE 3 DUL, 7219-A, 7219A P4 DUL, 3MM-219 DUL |
| Arrangement Configuration | Duplex universal (DU), single bearing |
| Precision Class | ABEC 7 / P4 |
| Additional Attributes | Minimum chamfer Rmin 2.1 mm; rmin 1.1 mm |
| Cage Type | Machined, outer-ring located |
| Series | SNFA E 200 (ISO 02) |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Contact Angle | 25° |
| Preload | Light (L) |
| Cross Reference 1 | Fafnir 3MM219WI |
|---|---|
| Cross Reference 2 | SKF 7219 ACD/P4A |
SNFA E295-7CE3DUL-1/2PR is one super-precision angular contact ball bearing from a duplex universal pair, SNFA E 200 series, ISO dimension series 02, size 7219. Bore Diameter: 95 mm. Outside Diameter: 170 mm. Overall Width: 32 mm. Contact Angle: 25°. Precision Class: ABEC 7 / P4. Preload: Light.
E2 — SNFA E 200 series, ISO dimension series 02.
95 — bore diameter, 95 mm.
7 — ABEC 7 precision.
C — stratified textile resin (phenolic) cage.
E — cage located on the outer ring.
3 — 25° nominal contact angle.
DU — duplex universal. Ground for back-to-back, face-to-face or tandem mounting with a matching DU bearing.
L — light preload.
-1/2PR — one bearing of the pair.
Dynamic Load Rating: 11,190 daN (SNFA C33 rating). Static Load Rating: 12,800 daN (C0). Cage Material: Phenolic. Cage Type: Machined, outer-ring located. The 25° angle and the heavy 02 section give high combined radial and axial capacity for large spindles and rotary tables.
Minimum chamfer, outer ring (Rmin): 2.1 mm. Minimum chamfer, inner ring (rmin): 1.1 mm. Closure Type: Open. Snap Ring: No.
Unit Quantity: 1 Pc. One universally ground bearing from a DUL pair.
ISO size 7219, 95 x 170 x 32 mm, 25°, ABEC 7. Same envelope and angle as Fafnir 3MM219WI and SKF 7219 ACD/P4A.
