SKF 7312 BEY/DGCB angular contact ball bearing, 60 x 130 x 31 mm, 40° contact angle, pressed brass cage. Open, single row, 95.6 kN dynamic rating.
List Price
$169.34
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7312 BEY/DGCB |
| Model | 7312BEYDGCB |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 60 mm |
| OD | 130 mm |
| Width | 31 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7300 |
| Base Number | 7312 |
| Industry Terms | angular contact ball bearing, 40 degree angular contact, 73 series bearing, single row angular contact |
| Common Misspellings | 7312BEY DGCB, 7312 BEYDGCB, 7312-BEY, 7312BE Y |
| Overall Width | 31 mm |
| Mpn Variants | 7312 BEY/DGCB, 7312-BEY-DGCB, 7312BEYDGCB, 7312BEY/DGCB, 7312 BEY |
| Arrangement Configuration | Single bearing |
| Additional Attributes | Fatigue load limit: 3 kN; Reference speed: 6,000 rpm; Internal design: SKF E (optimised) |
| Cage Type | Pressed window, ball-centred |
| Dynamic Load Rating | 95,600 N |
| Static Load Rating | 69,500 N |
| Rolling Elements | Ball |
| Cage Material | Pressed brass |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 6,000 rpm |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 40° |
| Closure Type | Open |
| Cross Reference 1 | NTN 7312B |
|---|---|
| Cross Reference 2 | Koyo 7312B |
| Cross Reference 3 | FAG 7312-B-XL-TVP - polyamide cage, not brass |
SKF 7312 BEY/DGCB single-row angular contact ball bearing, 60 x 130 x 31 mm, 40° contact angle, open, with a pressed brass window cage. Unit Quantity: 1 Pc.
7312 — ISO 73 medium series, bore code 12 = 60 mm bore, 130 mm OD, 31 mm width.
B — 40° contact angle.
E — SKF optimised internal design.
Y — pressed brass window cage, ball-centred.
Bore Diameter: 60 mm.
Outside Diameter: 130 mm.
Overall Width: 31 mm.
Contact Angle: 40°.
Dynamic Load Rating: 95,600 N.
Static Load Rating: 69,500 N.
Fatigue Load Limit: 3 kN.
Limiting Speed: 6,000 rpm.
Reference Speed: 6,000 rpm.
Cage Material: Pressed brass.
Closure Type: Open.
Number Of Rows: 1.
Bore Type: Straight.
Series: 7300. Base Number: 7312. Single-row bearing with a 40° contact angle, carrying axial load in one direction together with radial load.
Same size and 40° contact angle: NTN 7312B, Koyo 7312B. FAG 7312-B-XL-TVP is the same size and angle with a polyamide cage.
60 mm bore, 130 mm outside diameter and 31 mm width, with a 40° contact angle.
Dynamic load rating 95,600 N, static load rating 69,500 N and fatigue load limit 3 kN.
B is the 40° contact angle, E is SKF optimised internal design, and Y is a pressed brass window cage.
