Availability:
Out of stock
Precision angular contact ball bearing, 60 x 95 x 18 mm, 25 degree contact angle, ABEC 3 class, phenolic cage, open design, straight bore.
List Price
$114.73
Out of stock
Out of stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing - 17 mm ID, 35 mm OD, 10 mm Width, 25° Contact Angle, ABEC 7 / P4, Light Preload, Open.$50.24
Super-Precision Angular Contact Ball Bearing – Straight Bore, 55 mm ID, 100 mm OD, 21 mm Width, Open, 25° Contact Angle, ABEC 7, Medium Preload$51.26
Super-Precision Angular Contact Ball Bearing Duplex Pair – 15 mm Bore x 32 mm OD x 9 mm Wide, 25° Contact Angle, Phenolic Cage, ABEC 7, Medium Preload$66.29
Super Precision Angular Contact Ball Bearing - Straight Bore, 40 mm ID, 80 mm OD, 18 mm Width, Open, 15° Contact Angle, ABEC 7 / P4, Universally Ground$97.14| MFR / Brand | RHP |
|---|---|
| MPN | 7012ETP6 |
| Model | 7012 E T P6 / 3MM9112WI CR |
| Bearing Type | Angular Contact Ball Bearing, Open |
| OD | 95 mm |
| Base Number | 7012 |
|---|---|
| Overall Width | 18 mm |
| Bore Shaft Size | 60 mm |
| Mpn Variants | 7012ETP6; 7012E; 7012-E-T-P6; 3MM9112WI CR |
| Precision Class | ISO Class 6 / ABEC 3 (RHP EP3) |
| Additional Attributes | Chamfer r min 1.1 mm; chamfer r1 min 0.6 mm; shaft abutment d1 min 67 mm; housing abutment D1 max 88 mm; housing abutment D2 max 90 mm; internal volume 18.0 cm³; lubrication jet pitch circle dT 72.5 mm; effective load centre a 27.1 mm |
| Material | High Carbon Chrome Steel |
| Cage Type | Laminated |
| Dynamic Load Rating | 33.0 kN |
| Static Load Rating | 29.1 kN |
| Precision Rating | ABEC 3 / ISO Class 6 |
| Series | 7000 (ISO dimension series 10) |
| Rolling Elements | Ball |
| Item Weight | 0.407 kg |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Lubricant | Grease or oil |
| Contact Angle | 25° |
| Design Units | Metric |
| Part Number | 7012ETP6 |
This is a single RHP precision single-row angular contact ball bearing, catalogue designation 7012ETP6. Bore: 60 mm, Outside Diameter: 95 mm, Overall Width: 18 mm. Contact Angle: 25°, with Rolling Elements: Ball, Number Of Rows: 1, Bore Type: Straight and Closure Type: Open. Material: High Carbon Chrome Steel for the rings and balls. Design Units: Metric.
70 / 7012 — the ISO 7012 size in dimension series 10, 60 x 95 x 18 mm.
E — 25° contact angle.
T — laminated phenolic cage.
P6 — RHP EP3, ISO Class 6, ABEC 3.
The 25° contact angle gives the bearing appreciable thrust capacity in one direction while still carrying radial load, the usual choice where a spindle or shaft is located axially by an opposed bearing. Dynamic Load Rating: 33.0 kN and Static Load Rating: 29.1 kN, both class-independent geometry-derived figures for this size and angle. Precision Class: ISO Class 6 / ABEC 3 (RHP EP3). Precision rating: ABEC 3. Cage Material: Phenolic. Cage Type: Laminated, which keeps rotating mass low and tolerates marginal lubrication. Lubricant: Grease or oil. Item weight: 0.407 kg.
Chamfer dimensions are r min 1.1 mm and r1 min 0.6 mm. Shaft abutment diameter d1 min 67 mm; housing abutment D1 max 88 mm and D2 max 90 mm. Effective load centre a: 27.1 mm from the bearing face. Internal volume: 18.0 cm³. Lubrication jet pitch circle dT: 72.5 mm.
Unit Quantity: 1 Pc. Series: 7000, ISO dimension series 10. Base Number: 7012. Part Number: 7012ETP6.
Equivalent designations for this size, angle and cage include 7012E, 7012-E-T-P6 and 3MM9112WI CR.
$137.64
92 in stock
