FAG7210B.P5.ULAngular Contact Bearings – 50 mm ID, 90 mm OD, 20 mm Width, Open, 40°, Light preload.

Product Description

What this part is:

FAG 7210B.P5.UL single-row angular contact ball bearing, universal design with light preload. Unit Quantity: 1 Pc. Bore Diameter: 50 mm. Outside Diameter: 90 mm. Overall Width: 20 mm. Contact Angle: 40°. Precision Class: ABEC 5 / P5.

Decoding the designation:

7210B — FAG designation for the ISO 7210 size, 50 x 90 x 20 mm, with the B suffix denoting a 40° contact angle.

P5 — FAG precision grade, equivalent to ABEC 5.

UL — universal design with light preload: matchable with a second bearing of the same designation for a duplex pair.

Specifications:

Bore Diameter: 50 mm. Outside Diameter: 90 mm. Overall Width: 20 mm. Contact Angle: 40°. Precision Class: ABEC 5 / P5. Preload: light. Closure Type: open. Rolling Elements: ball. Bearing Material: bearing steel.

Dimensions and mounting:

Series: 7200. Mounting Arrangement: universal (U), matchable back-to-back, face-to-face or tandem. Harmonization Code: 8482.10.5028.

Compatibility and replacement:

Same envelope and 40° contact angle, standard precision and not universally ground: SKF 7210 BEP, NSK 7210B.

Frequently asked questions:

What is the contact angle of the FAG 7210B.P5.UL?

40°. The B suffix denotes a 40° contact angle.

What size is the FAG 7210B.P5.UL?

50 mm bore, 90 mm outside diameter and 20 mm width.

What does UL mean in the designation?

UL marks a universal design with light preload, matchable with a second bearing of the same designation.
