Availability:
2 in stock
Angular contact ball bearing, 40 x 80 x 18 mm, 40° contact angle, ISO P5 accuracy, universally matchable to zero axial clearance when paired.
List Price
$97.85
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| Model | 7208 B P5 UO |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 40 mm |
| OD | 80 mm |
| Width | 18 mm |
| Material | Chrome Steel |
|---|---|
| Series | 72 |
| Base Number | 7208 |
| Bore Shaft Size | 40 mm |
| Mpn Variants | 7208B.P5.UO; 7208-B-P5-UO; 7208 B P5 UO; 7208B; 7208-B |
| Arrangement Configuration | Universally matchable single bearing |
| Precision Class | ISO P5 (ABEC 5) |
| Dynamic Load Rating | 34 kN |
| Static Load Rating | 23.5 kN |
| Precision Rating | ISO P5 (ABEC 5) |
| Rolling Elements | Ball |
| Item Weight | 0.84 lb (0.379 kg) |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Harmonization Code | 8482.10.5028 |
| Contact Angle | 40° |
| Preload | Universally matchable, zero axial clearance when paired (UO) |
| Design Units | Metric |
| Bearing Material | Chrome Steel |
| Part Number | 7208-B-P5-UO |
| Cross Reference 1 | FAG 7208-B-TVP-UA - normal tolerance, small axial clearance |
|---|---|
| Cross Reference 2 | FAG 7208-B-TVP-UL - normal tolerance, light preload |
| Cross Reference 3 | FAG 7208-B-XL-TVP-P5-UL - X-life, higher ratings, light preload |
FAG 7208-B-P5-UO single-row angular contact ball bearing. Bore: 40 mm. Outside Diameter: 80 mm. Overall Width: 18 mm. Contact Angle: 40°. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Precision Class: ISO P5 (ABEC 5). Bearing Material: Chrome steel. Dynamic Load Rating: 34 kN. Static Load Rating: 23.5 kN. Item Weight: 0.379 kg (0.84 lb).
7208 — ISO 72 dimension series at a 40 mm bore, giving a 40 x 80 x 18 mm envelope.
B — 40° contact angle on a 72xx series bearing.
P5 — ISO tolerance class 5, equivalent to ABEC 5.
UO — universally matchable, set to zero axial clearance when two bearings are mounted together.
A 40° contact angle is the high-thrust end of the angular contact range. At this size it carries far more axial load than a 15° or 25° execution and runs at a lower speed ceiling for it.
ISO P5 holds bore, outside diameter, width and running accuracy tighter than normal class, so shaft location is closer and running runout is lower — which is what makes the pair worth setting to a defined axial condition in the first place.
Universal matchability means any two of these can be stacked back-to-back, face-to-face or in tandem straight from stock, and the pair comes out at zero axial clearance without shimming or grinding.
Dynamic Load Rating 34 kN sets the L10 life; Static Load Rating 23.5 kN sets the limit on permanent raceway indentation.
Unit Quantity: 1 Pc. Single bearing, open, straight bore, universally matchable.
Cross-Reference 1: FAG 7208-B-TVP-UA – normal tolerance, small axial clearance. Cross-Reference 2: FAG 7208-B-TVP-UL – normal tolerance, light preload. Cross-Reference 3: FAG 7208-B-XL-TVP-P5-UL – X-life, higher ratings, light preload. All are 40 x 80 x 18 mm.
Searchable designation forms: 7208B.P5.UO, 7208-B-P5-UO, 7208 B P5 UO, 7208B, 7208-B.
