Industrial Part Identification
When a part fails, it’s natural to look for the part number. It’s the first
Availability:
1 in stock
List Price
$41.61
1 in stock
1 in stock
Get Estimated Arrival Date
| MFR / Brand | INA |
|---|---|
| MPN | PCJT45 |
| Model | PCJT-45 |
| ID | 45mm |
| Series | PCJT |
|---|---|
| Condition | New – Open box |
| Type | Bearing Housing |
| Lubricant | Grease |
| Material | Cast Iron |
| Bolt Center To Center | 5.6563 in |
| Number Of Bolt Holes | 2 |
| Bolt Center To Center Length | 5.6563 in |
| Number Of Bolt Holes For Fasteners | 2 |
| Category 1 | Bearings & Bushings |
| Category 2 | Business & Industrial |
| Category 3 | Industrial Automation & Motion Controls |
| Category 4 | Mechanical Power Transmission |
| Category 5 | Mounted Bearings & Housings |
| Min Temp | -20°C |
| Dynamic Load Rating | 32.5 kN / 7300 lbf |
| Static Load Rating | 20.4 kN / 4600 lbf |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Ball |
| Max Temp | 100°C |
| Bearing Type | 2-Bolt Flange Unit |
| Item Weight | 3.50 lbs |
| Limiting Speed | 3500 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Internal Clearance | CN |
| Duty Type | Standard Duty |
| Locking Device | Eccentric Collar |
| Relubrication Feature | Yes |
| Harmonization Code | 84832040 |
| Housing Material | Cast Iron |
| Expansion Type | Non-Expansion |
| Cross Reference 1 | SKF FY 45 TF |
|---|---|
| Cross Reference 2 | NTN UELFL209D1 |
| Cross Reference 3 | FAG FL209 |
The INA PCJT45 Flanged Mount Bearing Unit with collar is a premium-quality bearing housing designed for industrial automation and motion control applications. Made with a durable cast iron housing and a straight bore diameter of 45mm, this bearing unit is suitable for standard duty use with a dynamic load rating of 32.5 kN. It features a single rubber seal for protection against contaminants, a limiting speed of 3500 rpm, and a static load rating of 20.4 kN. The bearing unit also includes a locking device with an eccentric collar for secure mounting and is relubricable with grease for easy maintenance. Made in Germany by INA, this bearing unit is a reliable choice for demanding mechanical power transmission applications.
