Heidenhain263329-47 ROD 121B 1024Incremental Rotary Encoder — 1024 Lines, TTL Output, Solid Shaft, 1 m Cable

Condition: New

Availability:

3 in stock

Heidenhain 263329-47 ROD 121B 1024 incremental rotary encoder with solid shaft, 1024 lines, TTL square-wave output, 1.00 m cable with connector. New.

Same day shipment

List Price

$268.99

3 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

3 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandHeidenhain
MPN263329-47 ROD 121B 1024
ModelROD-121B-01024

Technical Specifications

Base NumberROD 121B
Industry Termsincremental encoder; rotary encoder; shaft encoder; TTL encoder
Output TypeTTL
Encoding TypeIncremental
Shaft TypeSolid shaft
Mpn Variants263329-47; 263-329-47; ROD 121B 1024; ROD-121B-01024; ROD 121 1024
Additional AttributesLine Count: 1024; Cable Length: 1.00 m; ID Number: 263329-47
TypeIncremental Rotary Encoder
Seller Part Number: B-DB1#ED2KF5

Product Description

What this part is:

Heidenhain ROD 121B, ID 263329-47, is an incremental rotary encoder with integral bearing and solid shaft for separate shaft coupling. Line Count: 1024. Output Signal: TTL square-wave. Cable: 1.00 m with connector. Unit Quantity: 1 Pc. Country of origin: Germany.

Decoding the designation:

ROD 121B — Heidenhain incremental rotary encoder, ROD 100 family, solid shaft.

1024 — 1024 lines per revolution.

263329-47 — Heidenhain ID number for this exact execution.

Specifications:

Encoding Type: Incremental. Output Type: TTL. Line Count: 1024 per revolution. Shaft Type: solid shaft. Cable Length: 1.00 m. Termination Type: cable with connector. Series: ROD 100. ID Number: 263329-47.

Dimensions and mounting:

Construction: integral bearing with solid shaft, for separate shaft coupling.

Compatibility and replacement:

Manufacturer: Heidenhain. Written forms of this number: 263329-47; 263-329-47; ROD 121B 1024; ROD-121B-01024; ROD 121 1024.

Frequently asked questions:

What is the Heidenhain 263329-47?

A ROD 121B incremental rotary encoder, 1024 lines, with an integral bearing and solid shaft.

What output does the 263329-47 have?

TTL square-wave output on a 1.00 m cable with connector.

What does the ID 263329-47 identify?

The Heidenhain ID number for this exact execution of the ROD 121B 1024.
