SiemensAnalogue Closed-Loop Control Card, Single-Axis DC Feed Drive, SIMODRIVE 210 Rack Plug-In

Product Description

What this part is

Siemens SIMODRIVE 210 closed-loop control card for a DC feed drive. Brand: Siemens. Part Number: 6RB2100-0NA01. Board Number: 462 110.9070.01. Plug-In Module Fitted: 6RB2100-0SA01. Product Type: analogue closed-loop control card. Axes: 1. Control Type: analogue. Drive Type: DC feed drive. Controller Platform: SIMODRIVE 210. Unit Quantity: 1 Pc. Country of Origin: Germany.

Decoding the order code

6RB2 — the Siemens order-number group for SIMODRIVE 210 DC drive equipment.

100 — the card type number for the closed-loop control card in that range.

0NA01 — the execution code for the analogue single-axis control card.

462 110.9070.01 — the internal Siemens board number printed on the assembly, the marking used to identify the card in a drive.

What these specs mean in practice

Axes: 1. Control Type: analogue. The card closes the speed and current loops around one DC servomotor, taking an analogue speed reference from the numerical control and producing the firing commands for the drive’s power section. One card serves one axis, so a three-axis machine carries three of them. An analogue reference interface is what lets a SIMODRIVE 210 sit behind almost any CNC that can output a plus or minus 10 V command.

Mounting data

Mounting Type: plug-in card for a SIMODRIVE 210 drive rack slot. Connector Style: backplane edge connector, with signal terminations at the card front.

Quantity and configuration

Unit Quantity: 1 Pc. Control card with the 6RB2100-0SA01 plug-in module fitted. Condition: new takeout, tested.

Interchange guidance
