Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Double-row angular contact ball bearing, 35 x 72 x 27 mm, straight bore. 30-degree contact angle, shields both sides, pressed steel cage, 2 Pcs.
List Price
$52.67
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | INA |
|---|---|
| MPN | 3207J2Z |
| Model | 3207ZZ 5207ZZ |
| ID | 35 mm |
| OD | 72 mm |
| Width | 27 mm |
| Material | Chrome steel |
|---|---|
| Lubricant | Grease |
| Series | 32 |
| Base Number | 3207 |
| Industry Terms | Double row angular contact ball bearing, 5200 series |
| Total Width | 27 mm |
| Overall Width | 27 mm |
| Bore Shaft Size | 35 mm |
| Mpn Variants | 3207J2Z, 3207 J 2Z, 3207-J-2Z, 3207ZZ, 3207 2Z, 5207ZZ, 5207 |
| Rolling Elements | Balls |
| Bearing Type | Angular Contact Ball Bearing, Double Shield |
| Cage Material | Pressed steel |
| Number Of Rows | 2 |
| Bore Type | Cylindrical |
| Snap Ring Included | Without Snap Ring |
| Internal Clearance | CN |
| Harmonization Code | 8482.1 |
| Contact Angle | 30° |
| Design Units | Metric |
| Bearing Material | Chrome steel |
| Part Number | 3207-J-2Z |
| Cross Reference 1 | FAG 3207-BD-XL-2Z (current XL execution) |
|---|---|
| Cross Reference 2 | NSK 3207B-2Z |
| Cross Reference 3 | NTN 5207SCZZ |
| Cross Reference 4 | 5207 (MRC/Fafnir number) |
3207 double-row angular contact ball bearing, straight bore, shielded on both sides. Bore / Shaft Size: 35 mm. Outside Diameter: 72 mm. Overall Width: 27 mm (1-1/16 in). Contact Angle: 30°. Number Of Rows: 2. Rolling Elements: Balls. Bore Type: Cylindrical, straight. Closure Type: Shields both sides. Cage Material: Pressed steel. Internal Clearance: CN, axial. Design Units: Metric. Unit Quantity: 2 Pcs.
32 — the double-row angular contact ball bearing series, two ball rows in one pair of solid rings, without a filling slot.
07 — the bore code: 07 x 5 gives the 35 mm bore.
J — pressed steel cage.
2Z — non-contact shields on both sides.
30° — the contact angle carried by the 3200 series.
Bearing Type: Double-row angular contact ball bearing. Two ball rows at opposing 30° contact angles in one pair of rings. Bearing Material: Chrome steel. Series: 32. Base Number: 3207. Part Number: 3207-J-2Z. Harmonization Code: 8482.1.
Shaft seat 35 mm straight; housing bore 72 mm; seat length 27 mm (1-1/16 in). A single seat locates the shaft in both axial directions. Each bearing is a complete double-row unit and not a matched or preloaded set.
3207 is the ISO designation for this 35 x 72 x 27 mm envelope; 5207 is the number in the MRC and Fafnir scheme, and ZZ is the shield code used in place of 2Z. Related numbers: FAG 3207-BD-XL-2Z (current XL execution), NSK 3207B-2Z and NTN 5207SCZZ. Also written 3207J2Z, 3207 J 2Z, 3207-J-2Z, 3207ZZ, 3207 2Z, 5207ZZ and 5207.
35 mm bore, 72 mm outside diameter, 27 mm (1-1/16 in) width.
30°, two ball rows.
Non-contact shields on both sides (2Z).
$144.56
12 in stock
$141.11
255 in stock
