Availability:
1 in stock
Double-row spherical roller bearing, 45 x 85 x 23 mm, straight bore, C4 internal clearance, W33 lubrication groove and radial holes, 2° misalignment.
List Price
$68.18
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 22209 CCJ/C4W33 |
| Model | 22209 CC/CJ/C C4 W33 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 45 mm |
| OD | 85 mm |
| Width | 23 mm |
| Series | 22200 |
|---|---|
| Material | Bearing Steel |
| Lubricant | Grease or oil |
| Base Number | 22209 |
| Industry Terms | double row spherical roller bearing; self-aligning roller bearing |
| Common Misspellings | 22209CCJ C4W33; 22209 CJC4 W33; 22209CCJC4 W33 |
| Bore Shaft Size | 45 mm |
| Mpn Variants | 22209CCJC4W33; 22209 CCJ C4 W33; 22209 CC/CJ/C C4 W33; 22209-CCJ/C4W33 |
| Rolling Elements | Spherical Rollers |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Internal Clearance | C4 |
| Harmonization Code | 8482.30.00 |
| Part Number | 22209CCJC4W33 |
| Maximum Permissible Misalignment | 2° |
| Application Types | Gearboxes; conveyors; crushers and vibrating screens; industrial fans |
| Cross Reference 1 | FAG 22209-E1-C4 (related, no W33 in designation) |
|---|---|
| Cross Reference 2 | Timken 22209CJ-C4 (related, no W33 in designation) |
SKF 22209 CCJ/C4W33 double-row spherical roller bearing, 45 x 85 x 23 mm, straight bore, C4 radial internal clearance, with a W33 lubrication groove and three radial holes in the outer ring. Takes high radial load and thrust in both directions, with 2° of permissible misalignment. One complete bearing: inner ring, two rows of rollers with cages, and the outer ring. Unit Quantity: 1 Pc.
222 — dimension series for a double-row spherical roller bearing.
09 — bore code, 45 mm.
CC — cage execution: two window-type pressed steel cages with a loose guide ring.
CJ — alternate cage code on the same envelope.
C4 — radial internal clearance group, wider than both CN and C3.
W33 — annular groove machined into the outer ring outside diameter with three radial holes drilled through to the roller path.
Bearing Type: Spherical roller bearing. Series: 22200. Number Of Rows: 2. Rolling Elements: Spherical rollers. Bore Diameter: 45 mm. Outside Diameter: 85 mm. Overall Width: 23 mm. Bore Type: Straight. Internal Clearance: C4. Maximum Permissible Misalignment: 2°. Lubricant: grease or oil. Closure Type: Open. Harmonization Code: 8482.30.00. Unit Quantity: 1 Pc.
Bore Diameter: 45 mm, cylindrical. Outside Diameter: 85 mm. Width: 23 mm. The W33 groove distributes lubricant around the outer ring outside diameter and the three radial holes carry it inward to the rolling elements, so grease or oil is fed from the outside diameter.
FAG 22209-E1-C4 and Timken 22209CJ-C4 share the 45 x 85 x 23 mm envelope with C4 clearance; neither carries W33 in its designation. Also listed as 22209CCJC4W33, 22209 CCJ/C4W33, 22209 CCJ C4 W33 and 22209 CC/CJ/C C4 W33.
Bore Diameter: 45 mm. Outside Diameter: 85 mm. Overall Width: 23 mm.
W33 is an annular groove in the outer ring outside diameter with three radial holes through to the roller path, used to feed lubricant.
C4 is the radial internal clearance group, wider than CN and C3.
