Timing Belt Pulleys and V-Belt Sheaves: Matching Belt Drive Components Correctly
Belt drives may appear simple, consisting of two wheels and a belt for power transfer.
Availability:
2 in stock
Spherical roller bearing, 60 x 110 x 28 mm, 1:12 tapered bore, C3 clearance, W33 lubrication groove, 178,000 N dynamic rating. Mounts on an H312 adapter sleeve.
List Price
$51.88
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NSK |
|---|---|
| MPN | 22212EAKE4C3 |
| Model | 22212EAKE4 C3 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 60 mm |
| OD | 110 mm |
| Width | 28 mm |
| Material | Chrome Steel |
|---|---|
| Series | 22200 |
| Lubricant | Grease or oil |
| Dynamic Load Rating | 178,000 N |
| Static Load Rating | 174,000 N |
| Rolling Elements | Spherical Roller |
| Item Weight | 1.13 kg |
| Cage Material | Pressed steel |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | No |
| Relubrication Feature | W33 equivalent (E4): outer ring groove and holes |
| Harmonization Code | 8482.30.00.80 |
| Internal Clearance | C3 |
| Limiting Speed | 4,800 rpm grease; 6,000 rpm oil |
| Mpn Variants | 22212EAKE4C3, 22212EAKE4 C3, 22212 EAKE4 C3, 22212K W33 C3 |
| Compatible With Replaces | Adapter sleeve H312 |
| Closure Type | Open |
| Cross Reference 1 | SKF 22212 EK/C3 |
|---|---|
| Cross Reference 2 | FAG 22212-E1-K-C3 |
| Cross Reference 3 | Timken 22212KEJW33C3 |
| Cross Reference 4 | Koyo 22212RHRKW33C3 |
NSK 22212EAKE4C3 is a double-row spherical roller bearing with a 1:12 tapered bore, pressed steel cages, an outer-ring lubrication groove with holes, and C3 internal clearance. Bore Diameter: 60 mm. Outside Diameter: 110 mm. Width: 28 mm.
22212 — spherical roller bearing, 222 series, 60 mm bore, 60 x 110 x 28 mm.
EA — NSK high-capacity design with pressed steel cages.
K — 1:12 tapered bore.
E4 — lubrication groove and holes in the outer ring, the NSK equivalent of W33.
C3 — internal clearance greater than normal.
Rolling Elements: Spherical Roller. Number Of Rows: 2. Cage Material: Pressed steel. Bore Type: Tapered 1:12. Internal Clearance: C3. Lubricant: Grease or oil. Dynamic Load Rating: 178,000 N. Static Load Rating: 174,000 N. Limiting Speed: 4,800 rpm grease; 6,000 rpm oil. Item Weight: 1.13 kg.
Bore Diameter: 60 mm, tapered 1:12. Outside Diameter: 110 mm. Width: 28 mm. Mounts on an H312 adapter sleeve with KM and MB locknut and washer, or directly on a tapered journal.
Interchanges with SKF 22212 EK/C3, FAG 22212-E1-K-C3, Timken 22212KEJW33C3 and Koyo 22212RHRKW33C3. MPN variants: 22212EAKE4C3, 22212EAKE4 C3, 22212 EAKE4 C3, 22212K W33 C3.
The H312 adapter sleeve, which seats the 60 mm tapered bore on a smaller shaft.
E4 is the outer-ring lubrication groove with holes, equivalent to W33 on other makes.
C3, greater than normal internal clearance.
$44.26
14 in stock
$44.26
14 in stock
$51.83
10 in stock
