Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Spherical roller bearing, 170 x 310 x 86 mm, 1:12 tapered bore, polyamide cage, W33-type lubrication groove. FAG E design, normal clearance; sleeve H3134.
List Price
$659.61
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 22234ESKTVPB |
| Model | 22234-ES-K-TVPB |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 170 mm |
| OD | 310 mm |
| Width | 86 mm |
| Material | Bearing Steel |
|---|---|
| Series | 222 |
| Mpn Variants | 22234-ES-K-TVPB, 22234ESK.TVPB, 22234ESKTVPB, 22234E |
| Compatible With Replaces | Adapter sleeve H3134; withdrawal sleeve AH3134A |
| Rolling Elements | Spherical Roller |
| Cage Material | Polyamide |
| Number Of Rows | 2 |
| Bore Type | Tapered 1:12 |
| Snap Ring Included | Without Snap Ring |
| Internal Clearance | CN |
| Lubricant | Grease or oil |
| Relubrication Feature | Lubrication groove and holes in outer ring (W33) |
| Harmonization Code | 8482.30.00 |
| Cross Reference 1 | SKF 22234 CCK/W33 |
|---|---|
| Cross Reference 5 | KOYO 22234RK |
FAG 22234-ES-K-TVPB is a double-row spherical roller bearing in the 222 series with a 1:12 tapered bore. Bore Diameter: 170 mm (small end of taper). Outside Diameter: 310 mm. Overall Width: 86 mm. Bore Type: Tapered 1:12. Internal Clearance: CN. Rolling Elements: Spherical Roller.
22234 — spherical roller bearing, 222 series; bore code 34 = 170 mm.
E — FAG increased-capacity internal design.
S — lubrication groove with radial holes in the outer ring (W33 equivalent).
K — tapered bore, taper 1:12.
TVPB — glass-fibre reinforced polyamide cage.
Cage Material: Polyamide. Lubricant: grease or oil, fed through the outer-ring groove and holes. Internal Clearance: CN. The tapered bore mounts on an adapter or withdrawal sleeve.
Adapter sleeve: H3134. Withdrawal sleeve: AH3134A.
Same envelope and tapered-bore configuration as FAG 22234-E1-XL-K and SKF 22234 CCK/W33.
