Double-row spherical roller bearing, 90 x 160 x 40 mm, straight bore, glass-fibre polyamide cage, C3 clearance, lubrication groove with three outer-ring holes.
List Price
$117.59
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 22218AS.TVPB.C3 |
| Model | 22218 A S TVPB C3 W33 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 90 mm |
| OD | 160 mm |
| Width | 40 mm |
| Material | Bearing Steel |
|---|---|
| Series | 22200 |
| Base Number | 22218 |
| Industry Terms | spherical roller bearing; self-aligning roller bearing; W33 bearing; barrel roller bearing; conveyor pulley bearing |
| Common Misspellings | 22218AS TVPB C3; 22218ASTVBP C3; FAG 22218ATVPBC3; 22218-AS-TVP-C3; 22218ASTVPC3 |
| Application Types | Fans and blowers; conveyor pulleys; gearboxes; vibrating equipment; pumps; process machinery |
| Bore Shaft Size | 90 mm (3.5433 in), cylindrical |
| Mpn Variants | 22218AS.TVPB.C3; 22218ASTVPBC3; 22218-AS-TVPB-C3; 22218 AS TVPB C3; 22218E |
| Rolling Elements | Spherical Roller |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Internal Clearance | C3 |
| Harmonization Code | 8482.30.00.80 |
| Part Number | 22218AS.TVPB.C3 |
| Cross Reference 1 | SKF 22218 E/C3 |
|---|---|
| Cross Reference 2 | NSK 22218EAE4C3 |
| Cross Reference 3 | Timken 22218EJW33C3 - steel cage |
| Cross Reference 4 | Koyo 22218RHRW33C3 |
FAG 22218AS.TVPB.C3 double-row spherical roller bearing, 90 x 160 x 40 mm, straight (cylindrical) bore, glass-fibre reinforced polyamide cage, C3 radial internal clearance, lubrication groove with three radial holes in the outer ring. Two rows of barrel-shaped rollers run on a shared spherical outer raceway, so the bearing self-aligns while carrying radial load and axial load in both directions. One bearing.
22218 — double-row spherical roller bearing, 90 x 160 x 40 mm, 222-series section.
AS — lubrication groove around the outer ring plus three radial lubrication holes, the FAG equivalent of the W33 feature.
TVPB — glass-fibre reinforced polyamide cage.
C3 — radial internal clearance greater than normal.
No K suffix — cylindrical bore.
Bearing Type: Spherical roller bearing, double row, self-aligning. Bore Diameter: 90 mm (3.5433 in), cylindrical. Outside Diameter: 160 mm. Overall Width: 40 mm. Number Of Rows: 2. Rolling Elements: Barrel rollers. Closure Type: Open. Cage Material: Glass-fibre reinforced polyamide. Internal Clearance: C3. Series: 22200 / 222-series. Base Number: 22218. Harmonization Code: 8482.30.00.80. Unit Quantity: 1 Pc.
Bore Type: Straight, cylindrical. The bearing mounts directly on a plain shaft seat; no adapter sleeve applies. The outer ring carries a lubrication groove and three radial holes.
Cylindrical-bore 22218 spherical roller bearings at C3 clearance with W33-type lubrication features: SKF 22218 E/C3, NSK 22218EAE4C3, Timken 22218EJW33C3 (steel cage) and Koyo 22218RHRW33C3. The tapered-bore 22218ASK.TVPB variant mounts on an adapter sleeve. Brass-cage forms such as 22218AS.MB have different cage material.
Bore Diameter: 90 mm, cylindrical. Outside Diameter: 160 mm. Overall Width: 40 mm.
AS is a lubrication groove around the outer ring plus three radial lubrication holes, the FAG equivalent of W33.
TVPB is a glass-fibre reinforced polyamide cage.
