SKF6211-2Z/C3Deep Groove Ball Bearing, 55 x 100 x 21 mm, Shields Both Sides, C3 Clearance, Grease Filled

Condition: New

Availability:

1 in stock

SKF 6211-2Z/C3 deep groove ball bearing, 55 x 100 x 21 mm, shields both sides, C3 clearance, grease filled, 46,200 N dynamic load rating, 7,000 rpm limiting.

Same day shipment

List Price

$23.97

1 in stock

Prefer eBay? Visit our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

1 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandSKF
MPN6211-2Z/C3
GTIN7316576681356
Model6211 2Z/ZZ C3/JEM
Bearing TypeDeep Groove Ball Bearing
ID55 mm
OD100 mm
Width21 mm

Technical Specifications

MaterialBearing steel
Base Number6211
Mpn Variants6211-2Z/C3; 6211-2Z-C3; 62112ZC3; 6211ZZC3; 6211 2Z C3; 6211-2Z C3
Unspsc31171504
Additional AttributesPerformance class: SKF Explorer; reference speed 14,000 rpm; filling slots: without; locating feature, outer ring: without; matched arrangement: no; coating: without; relubrication feature: without; sealing type: non-contact; eClass 23-05-08-01; UNSPSC 31171504; GTIN 7316576681356
Dynamic Load Rating46,200 N
Static Load Rating29,000 N
Series62
Rolling ElementsBall
Item Weight0.618 kg
Cage MaterialSheet metal
Number Of Rows1
Bore TypeCylindrical
Limiting Speed7,000 rpm
Internal ClearanceC3 (greater than Normal)
LubricantGrease
Bearing MaterialBearing steel
Closure TypeShield on both sides, non-contact (2Z)
Industry TermsDeep groove ball bearing; radial ball bearing; shielded ball bearing; 2Z bearing; ZZ bearing; C3 clearance bearing
Common MisspellingsSKF 62112Z/C3; 6211-ZZ-C3; 6211-22/C3; 6112-2Z/C3; 6211-2ZC3
Application TypesShaft supports carrying radial loads and axial loads in both directions; high-speed, low-noise rotating equipment
Overall Width21 mm
Manufacturer StatusActive (listed on skf.com)
Compatible With ReplacesISO 6211-2Z/ZZ C3 positions: 55 mm shaft, 100 mm housing bore, 21 mm width
Part Number6211-2Z/C3

Cross-References

Cross Reference 1FAG 6211-2Z-C3
Cross Reference 2NSK 6211ZZC3
Cross Reference 3NTN 6211ZZC3
Cross Reference 4Koyo 6211ZZC3
Cross Reference 5NACHI 6211ZZC3
Seller Part Number: B-AG2B2#RMGFIQ

Product Description

What this part is:

SKF 6211-2Z/C3 is a single row deep groove ball bearing with a non-contact shield on both sides, grease filled, in the SKF Explorer performance class, with C3 radial internal clearance. It carries radial loads and axial loads in both directions. Unit Quantity: 1 Pc. Condition: new.

Decoding the designation:

6 — SKF bearing type code: deep groove ball bearing.

2 — ISO dimension series 02.

11 — bore code; 11 × 5 = 55 mm bore.

2Z — shield on both sides (non-contact).

C3 — radial internal clearance greater than Normal.

Specifications:

Bore Diameter (d): 55 mm. Outside Diameter (D): 100 mm. Width (B): 21 mm. Basic Dynamic Load Rating: 46,200 N. Basic Static Load Rating: 29,000 N. Reference Speed: 14,000 rpm. Limiting Speed: 7,000 rpm. Number Of Rows: 1. Bore Type: Cylindrical. Cage: Sheet metal. Sealing: Shield on both sides. Sealing Type: Non-contact. Lubricant: Grease. Relubrication Feature: Without. Radial Internal Clearance: C3. Filling Slots: Without. Locating Feature, Outer Ring: Without. Matched Arrangement: No. Material: Bearing steel. Coating: Without. Performance Class: SKF Explorer. Product Net Weight: 0.618 kg. eClass: 23-05-08-01. UNSPSC: 31171504. GTIN: 7316576681356.

Dimensions and mounting:

55 mm cylindrical bore for a 55 mm shaft seat, 100 mm outside diameter for the housing bore, 21 mm wide. The outer ring has no locating feature (no snap ring groove), and the bearing has no filling slots.

Compatibility and replacement:

ISO 6211 boundary dimensions with 2Z/ZZ shields and C3 clearance. Interchanges: FAG 6211-2Z-C3, NSK 6211ZZC3, NTN 6211ZZC3, Koyo 6211ZZC3, NACHI 6211ZZC3. Related SKF versions: 6211-2RS1/C3 (contact seals both sides), 6211-Z/C3 (shield one side), 6211-2Z (Normal clearance). Also written 6211-2Z-C3, 6211 2Z C3 and 6211ZZC3.

Frequently asked questions:

What are the dimensions of the SKF 6211-2Z/C3?

55 mm bore, 100 mm outside diameter and 21 mm width.

What do 2Z and C3 mean?

2Z is a non-contact shield on both sides; C3 is radial internal clearance greater than Normal.

What speeds does SKF publish for it?

Reference speed 14,000 rpm and limiting speed 7,000 rpm.
