SKFNN 3005 K/SPDouble Row Cylindrical Roller Bearing – 25 mm Tapered Bore (1:12), 47 mm OD, 16 mm Width, Super-Precision SP

Product Description

What this part is:

SKF NN 3005 K/SP is a double-row cylindrical roller bearing with a 1:12 tapered bore in the SKF super-precision class, 25 mm bore, 47 mm outside diameter, 16 mm width. Open, non-locating design. Unit Quantity: 1 Pc.

Decoding the designation:

NN — double-row cylindrical roller design, with the rollers guided by integral ribs.

3005 — the size: 25 mm bore, 47 mm outside diameter, 16 mm width.

K — tapered bore, 1:12 taper.

SP — SKF super-precision class, with tighter bore, outside diameter and running accuracy tolerances than a standard bearing.

Specifications:

Bearing Type: Cylindrical Roller Bearing, double row, super-precision. Rolling Elements: Cylindrical Roller. Number of Rows: 2. Bore Type: Tapered, 1:12. Closure Type: Open. Series: NN30 (NN3000). Material: High Carbon Chrome Steel. Harmonization Code: 8482.50.00. Unit Quantity: 1 Pc.

Dimensions and mounting:

Bore Diameter: 25 mm (0.9843 in), tapered 1:12. Outside Diameter: 47 mm. Overall Width: 16 mm. Base Number: NN3005. Mounting: the 1:12 tapered bore seats directly on a tapered journal; no adapter sleeve is part of the design.

Compatibility and replacement:

Related part: SKF NN3005/SP, the straight-bore version of the same size. MPN variants: NN3005K/SP, NN-3005-K/SP, NN 3005 K SP, NN3005KSP, NN3005K.

Frequently asked questions:

What are the dimensions of the SKF NN 3005 K/SP?

Bore 25 mm (1:12 taper), outside diameter 47 mm, width 16 mm.

What does the K mean in SKF NN 3005 K/SP?

K is a tapered bore with a 1:12 taper.

How many rows of rollers does the SKF NN 3005 K/SP have?

Two rows of cylindrical rollers (NN).
