Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Single-row deep groove ball bearing, 80 mm bore x 140 mm OD x 26 mm wide, open, pressed steel cage. Dynamic load rating 75,400 N, normal CN clearance.
List Price
$47.54
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNR |
|---|---|
| MPN | 6216 |
| Model | SNR 6216 |
| Bearing Type | Ball Bearing, Open |
| ID | 80 mm |
| OD | 140 mm |
| Width | 26 mm |
| Material | Chrome Steel |
|---|---|
| Series | 6200 |
| Lubricant | Grease or oil |
| Base Number | 6216 |
| Industry Terms | deep groove ball bearing, open ball bearing, radial ball bearing, Conrad bearing, 6200 series |
| Common Misspellings | 6261, 621 6, 6126, 6216O |
| Overall Width | 26 mm |
| Mpn Variants | 6216, SNR 6216, 6216 open, 6216 CN |
| Precision Class | ABEC 1 / P0 |
| Min Temp | -40 °C |
| Dynamic Load Rating | 75,400 N |
| Static Load Rating | 54,300 N |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 1.35 kg (2.98 lb) |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 7,400 rpm |
| Internal Clearance | CN |
| Harmonization Code | 8482.10.50.68 |
| Application Types | Gearboxes; electric motors; pumps; general machinery |
| Cross Reference 1 | SKF 6216 |
|---|---|
| Cross Reference 2 | FAG 6216 |
| Cross Reference 3 | NSK 6216 |
| Cross Reference 4 | NTN 6216 |
| Cross Reference 5 | Koyo 6216 |
| Cross Reference 6 | Fafnir 216K |
| Cross Reference 7 | MRC 216S |
SNR 6216 open single-row deep groove ball bearing from NTN-SNR, radial contact, pressed steel cage. It carries radial load and axial load in both directions. Unit Quantity: 1 Pc.
62 — single-row deep groove ball bearing, ISO light series 02.
16 — bore code, 16 x 5 = 80 mm.
Bore Diameter: 80 mm. Outside Diameter: 140 mm. Width: 26 mm. Number Of Rows: 1. Rolling Elements: Ball. Closure Type: Open. Cage Material: Pressed steel. Internal Clearance: CN. Dynamic Load Rating: 75,400 N. Static Load Rating: 54,300 N. Fatigue Limit Load: 2,340 N. Reference Speed: 5,500 rpm. Limiting Speed: 7,400 rpm. Min Temp: -40 °C. Max Temp: 120 °C. Item Weight: 1.35 kg (2.98 lb).
Inner Ring Shoulder Diameter d1: 100 mm. Outer Ring Inner Diameter D1: 122 mm. Minimum Chamfer rs: 2 mm. Calculation Factor f0: 14.8. Snap Ring Included: No.
Open, normal-clearance 80 x 140 x 26 mm deep groove bearings: SKF 6216, FAG 6216, NSK 6216, NTN 6216, Koyo 6216, Fafnir 216K, MRC 216S. MPN Variants: 6216, SNR 6216, 6216 open, 6216 CN.
Bore 80 mm, outside diameter 140 mm, width 26 mm.
Dynamic Load Rating 75,400 N, Static Load Rating 54,300 N, Reference Speed 5,500 rpm, Limiting Speed 7,400 rpm.
No. It is an open bearing with a pressed steel cage and CN internal clearance.
