Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Deep groove ball bearing, 75 mm bore x 160 mm OD x 37 mm wide, ABEC 5 / P5 precision, phenolic cage, open. NTN 6315T1P5, also marked 6315-T1-P5. One piece.
List Price
$60.40
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NTN |
|---|---|
| MPN | 6315T1P5 |
| Model | 6315 T1 P5 |
| Bearing Type | Ball Bearing, Open |
| ID | 75 mm |
| OD | 160 mm |
| Width | 37 mm |
| Series | 6300 |
|---|---|
| Material | High Carbon Chrome Steel |
| Mpn Variants | 6315T1P5, 6315-T1-P5, 6315 T1 P5 |
| Precision Class | ABEC 5 / P5 |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Industry Terms | deep groove ball bearing; radial ball bearing; 6315 bearing; 75x160x37 bearing; ABEC 5 ball bearing; phenolic cage ball bearing; open ball bearing |
| Common Misspellings | NTN 6315 T1 P5; NTN 6315TIP5; NTN 6315T1 P5; NTM 6315T1P5; NTN6315T1P5 |
| Application Types | Electric motors; Gearboxes; Pumps; Industrial machinery; Machine tool spindles |
| Cross Reference 1 | Koyo 6315P5 |
|---|---|
| Cross Reference 2 | NSK 6315P5 |
NTN 6315T1P5 single row deep groove ball bearing, open type, with a phenolic cage and ABEC 5 precision. Bore Diameter: 75 mm. Outside Diameter: 160 mm. Overall Width: 37 mm.
6315 — single row deep groove ball bearing, 63 medium series, bore code 15 = 75 mm bore. 75 x 160 x 37 mm.
T1 — phenolic resin cage.
P5 — ISO tolerance class 5, equivalent to ABEC 5.
Bore Diameter: 75 mm. Outside Diameter: 160 mm. Overall Width: 37 mm. Cage Material: Phenolic. Precision Class: ABEC 5 / P5. Closure Type: Open. Bore Type: Straight. Rolling Elements: Ball. Number Of Rows: 1. Series: 6300. Snap Ring Groove: No. Unit Quantity: 1 Pc.
Chamfer Dimension r min: 2.1 mm.
ABEC 5 open 6315 equivalents in the 75 x 160 x 37 mm envelope: Koyo 6315P5 and NSK 6315P5.
75 mm bore, 160 mm OD, 37 mm wide.
A phenolic resin cage.
ISO tolerance class 5, equivalent to ABEC 5.
