Availability:
1 in stock
Deep groove ball bearing, 17 x 35 x 10 mm, ABEC 5 / P5 precision, open. 7,550 N dynamic rating, 20,000 rpm grease, 24,000 rpm oil. Pressed cage.
List Price
$24.40
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NTN |
|---|---|
| MPN | 6003-P5 |
| Model | 6003P5 |
| Bearing Type | Ball Bearing, Open |
| ID | 17 mm |
| OD | 35 mm |
| Width | 10 mm |
| Material | High Carbon Chrome Steel |
|---|---|
| Series | 6000 |
| Mpn Variants | 6003P5, 6003-P5, 6003 P5 |
| Precision Class | ABEC 5 / P5 |
| Dynamic Load Rating | 7,550 N |
| Static Load Rating | 3,350 N |
| Rolling Elements | Ball |
| Item Weight | 0.040 kg (0.088 lb) |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 20,000 rpm grease; 24,000 rpm oil |
| Internal Clearance | CN |
| Harmonization Code | 8482.10.50 |
| Cross Reference 1 | SKF 6003/P5 |
|---|---|
| Cross Reference 2 | FAG 6003-P5 |
| Cross Reference 3 | NSK 6003P5 |
| Cross Reference 4 | Koyo 6003P5 |
NTN 6003P5 single-row deep groove ball bearing, open, made to P5 precision. Bore Diameter: 17 mm. Outside Diameter: 35 mm. Overall Width: 10 mm. Precision Class: ABEC 5 / P5. Closure Type: Open. Rolling Elements: Ball. Cage Material: Pressed steel. Internal Clearance: CN. Material: High Carbon Chrome Steel.
6003 — single-row deep groove ball bearing, 10 dimension series, bore code 03: 17 x 35 x 10 mm.
P5 — ISO Class 5 precision, equivalent to ABEC 5.
Dynamic Load Rating: 7,550 N. Static Load Rating: 3,350 N. Limiting Speed: 20,000 rpm grease; 24,000 rpm oil. Item Weight: 0.040 kg (0.088 lb). Class 5 holds bore, OD and runout to tighter limits than standard Class 0, for quieter running and more accurate shaft location in spindles, motors and instruments.
Fillet Radius r min: 0.3 mm. Shaft Abutment Diameter da min: 19 mm. Housing Abutment Diameter Da max: 33 mm. Max Abutment Fillet ras: 0.3 mm.
Unit Quantity: 1 Pc.
Same 17 x 35 x 10 mm envelope at ABEC 5 / P5: SKF 6003/P5, FAG 6003-P5, NSK 6003P5, Koyo 6003P5.
