Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Single-row deep groove ball bearing, 100 x 215 x 47 mm, open both sides, straight bore, CN internal clearance, chrome steel, ISO 300 heavy series.
List Price
$103.72
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | MRC |
|---|---|
| MPN | 320S |
| GTIN | 097741009584 |
| Model | 6320 C3 |
| Bearing Type | Ball Bearing, Open |
| ID | 100 mm |
| OD | 215 mm |
| Width | 47 mm |
| Material | Bearing Steel |
|---|---|
| Series | 300 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Harmonization Code | 8482.10.50.68 |
| Base Number | 6320 |
| Industry Terms | Single row ball bearing, radial ball bearing, open ball bearing, 100mm bore ball bearing, heavy series ball bearing |
| Common Misspellings | MRC 320s bearing, MCR 320S, 320-5, 6320 bearing MRC, MRC320S |
| Total Width | 47 mm |
| Overall Width | 47 mm |
| Bore Shaft Size | 100 mm |
| Mpn Variants | 320S, 320-S, 320 S |
| Internal Clearance | CN |
| Design Units | Metric |
| Bearing Material | Chrome steel |
| Part Number | 320S |
| Cross Reference 1 | SKF 6320 |
|---|---|
| Cross Reference 2 | FAG 6320 |
| Cross Reference 3 | NSK 6320 |
| Cross Reference 4 | NTN 6320 |
| Cross Reference 5 | Timken 6320 |
| Cross Reference 6 | RHP 6320 |
| Cross Reference 7 | Koyo 6320 |
| Cross Reference 8 | MRC 320S |
| Cross Reference 9 | SNR 6320 |
MRC 320S single-row deep groove ball bearing. Bore: 100 mm. Outside Diameter: 215 mm. Overall Width: 47 mm. Total Width: 47 mm. Bearing type: Deep groove ball bearing. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Internal Clearance: CN. Bearing Material: Chrome steel. Series: 300. Base Number: 6320. Part Number: 320S. Design Units: Metric. Unit Quantity: 1 Pc. GTIN: 097741009584.
320 — ISO 300 heavy dimension series, bore code 20, giving a 100 mm bore.
S — MRC’s symbol for a single-row deep groove ball bearing, Conrad assembly.
Open both faces takes lubricant directly from the housing and runs cooler than a shielded or sealed execution at the same speed. CN clearance is the general-purpose radial internal clearance and suits an interference fit on the shaft with a normal temperature difference across the rings.
The 300 heavy series carries a larger ball complement on a thicker ring section than a 200-series bearing of the same bore, so radial capacity is higher for the same shaft diameter. At 215 mm outside diameter on a 100 mm shaft the section is 57.5 mm deep, which is what buys that capacity.
Straight cylindrical bore, mounted directly on a 100 mm shaft seat. Housing bore 215 mm. Ring width 47 mm across both rings.
Unit Quantity: 1 Pc. Single bearing, open both faces.
The 100 x 215 x 47 mm open envelope is the ISO 6320, built by every major maker to the same boundary dimensions. Cross-Reference 1: SKF 6320. Cross-Reference 2: FAG 6320. Cross-Reference 3: NSK 6320. Cross-Reference 4: NTN 6320. Cross-Reference 5: Timken 6320. Cross-Reference 6: RHP 6320. Cross-Reference 7: Koyo 6320. Cross-Reference 8: MRC 320S. Cross-Reference 9: SNR 6320.
MPN Variants: 320S, 320-S, 320 S. Industry Terms: single row ball bearing, radial ball bearing, open ball bearing, 100mm bore ball bearing. Common Misspellings: MRC 320s bearing, MCR 320S, 320-5, 6320 bearing MRC.
