Availability:
1 in stock
FAG 6201.TBH.P6 deep groove ball bearing, 12 x 32 x 10 mm, open, P6 (ABEC 3) tolerance. Unit Quantity: 10 Pcs. Current FAG successor: 6201-C.
List Price
$51.64
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 6201.TBH.P6 |
| Model | 6201.TBH.P6 |
| Bearing Type | Ball Bearing, Open |
| ID | 12 mm |
| OD | 32 mm |
| Width | 10 mm |
| Series | 6200 |
|---|---|
| Dynamic Load Rating | 8,000 N |
| Static Load Rating | 3,100 N |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 37,000 rpm |
| Harmonization Code | 8482.10 |
| Internal Clearance | CN |
| Industry Terms | deep groove ball bearing, radial ball bearing, ABEC 3 bearing |
| Overall Width | 10 mm |
| Mpn Variants | 6201.TBH.P6, 6201-TBH-P6, 6201TBHP6, 6201 TBH P6 |
| Compatible With Replaces | Successor: FAG 6201-C |
| Precision Class | ABEC 3 / P6 |
| Additional Attributes | Legacy FAG execution; current FAG successor 6201-C; P6 tolerance |
| Common Misspellings | FAG 6201 TBH P6; FAG 6201-TBH-P6; FAG 6201TBH P6; FAG 6201 TBHP6; FGA 6201.TBH.P6 |
| Application Types | electric motors; pumps; gearboxes; machine tools; general industrial machinery |
| Cross Reference 1 | SKF 6201/P6 |
|---|---|
| Cross Reference 2 | NSK 6201P6 |
| Cross Reference 3 | NTN 6201P6 |
| Cross Reference 4 | Koyo 6201P6 |
FAG 6201.TBH.P6 single-row deep groove ball bearing to P6 tolerance, open design. Unit Quantity: 10 Pcs.
6201 — ISO 62 series deep groove ball bearing, bore code 01 = 12 mm.
P6 — tolerance class P6, equivalent to ABEC 3.
Bore Diameter: 12 mm. Outside Diameter: 32 mm. Overall Width: 10 mm. Closure Type: Open. Precision Class: ABEC 3 / P6. Rolling Elements: Ball. Number Of Rows: 1. Internal Clearance: CN. Successor 6201-C data: Dynamic Load Rating: 8,000 N. Static Load Rating: 3,100 N. Limiting Speed: 37,000 rpm. Reference Speed: 24,600 rpm. Item Weight: 0.033 kg (0.07 lb) per bearing. Operating Temperature: -30 °C to 120 °C.
Envelope: 12 x 32 x 10 mm. Successor 6201-C data: Chamfer r min: 0.6 mm. Fillet ra max: 0.6 mm. Shaft Abutment da min: 16.2 mm. Housing Abutment Da max: 27.8 mm.
P6 crosses on the 12 x 32 x 10 mm envelope: SKF 6201/P6, NSK 6201P6, NTN 6201P6, Koyo 6201P6. Current FAG successor: 6201-C.
Bore Diameter: 12 mm. Outside Diameter: 32 mm. Overall Width: 10 mm.
Precision Class: ABEC 3 / P6.
Current FAG successor: 6201-C.
