SKF 6203 AY C78 single-row deep groove ball bearing, 17 x 40 x 12 mm, open both faces, 6200 light series, steel balls, CN internal clearance.
List Price
$8.46
795 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 6203 AY C78 |
| Model | 6203AYC78 |
| Bearing Type | Ball Bearing, Open |
| ID | 17 mm |
| OD | 40 mm |
| Width | 12 mm |
| Series | 6200 |
|---|---|
| Base Number | 6203 |
| Industry Terms | Deep groove ball bearing, radial ball bearing, 6203 bearing, open ball bearing |
| Bore Shaft Size | 17 mm |
| Mpn Variants | 6203AYC78, 6203 AY C78, 6203-AY-C78, 6203P5, 6203-P5, M203K |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Internal Clearance | CN |
| Design Units | Metric |
| Part Number | 6203 AY C78 |
| Common Misspellings | SKF 6203AYC 78; SKF 6203 AYC78; SFK 6203 AY C78; SKF 6203 A Y C78 |
| Application Types | Electric motors, pumps, fans, gearboxes, conveyors, general industrial machinery |
| Closure Type | Open |
SKF 6203 AY C78 single-row deep groove ball bearing, 6200 light dimension series, open both faces, steel balls. Bore 17 mm, outside diameter 40 mm, width 12 mm. Single bearing.
6 — single-row deep groove ball bearing.
2 — the 02 light dimension series: 40 mm outside diameter and 12 mm width on a 17 mm bore.
03 — bore code: 03 x 5 = 17 mm.
Bore Diameter: 17 mm. Outside Diameter: 40 mm. Overall Width: 12 mm. Number Of Rows: 1. Series: 6200. Closure Type: Open. Rolling Elements: Ball. Internal Clearance: CN. Unit Quantity: 1 Pc.
Bore: 17 mm, cylindrical. Outside Diameter: 40 mm. Overall Width: 12 mm. Both rings are non-separable.
MPN variants: 6203AYC78, 6203 AY C78, 6203-AY-C78, 6203P5, 6203-P5, M203K.
Bore 17 mm, outside diameter 40 mm, width 12 mm.
6 is a single-row deep groove ball bearing, 2 is the 02 light dimension series, and 03 is the bore code for a 17 mm bore.
One bearing, open on both faces (Unit Quantity: 1 Pc).
