Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
3 in stock
Super-precision angular contact ball bearing, 95 mm bore, 145 mm outside diameter, 24 mm width. 15 degree contact angle, ABEC 7, light preload, duplex-ground. One ring, half of a pair. Sold as 1 Pc.
List Price
$378.27
3 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SNFA |
|---|---|
| MPN | EX95-7CE1DUL |
| Model | 2MM-9119 DUL / 7019C P4 DUL / EX95-7-CE-1-DUL |
| Bearing Type | Angular Contact Ball Bearing |
| Base Number | EX95 |
|---|---|
| Industry Terms | super precision spindle bearing; machine tool bearing; angular contact ball bearing; duplex ground bearing; half pair |
| Common Misspellings | SNFA EX95 7CEIDUL; SFNA; SNAF; EX95-7CE1DUI; EX95 7CE1 DU L |
| Application Types | High-frequency machine tool spindles; grinding spindles; precision rotary tables |
| Bore Shaft Size | 95 mm (3.7402 in) |
| Mpn Variants | EX95-7CE1DUL-1/2PR; EX95-7CE1DUL; EX957CE1DUL; EX 95 7 CE1 DUL; EX-95-7-CE-1-DUL |
| Manufacturer Status | SNFA is a French super-precision maker later absorbed into SKF |
| Number Of Rows | 1 |
| Part Number | EX95-7CE1DUL |
An SNFA EX95-7CE1DUL super-precision angular contact ball bearing, single row, ground to duplex tolerances. One ring, half of a pair.
EX — SNFA E light dimension series.
95 — bore in millimetres, stated directly.
7 — ABEC 7 precision class.
CE1 — SNFA design block; the trailing 1 fixes the contact angle at 15°.
DUL — duplex-ground, light preload.
-1/2PR — half a pair, so one bearing.
A 15° contact angle favours speed and radial stiffness over thrust capacity, which is why it is the standard angle for high-frequency spindle front bearings. Light preload holds a lower running temperature and less frictional drag than the medium and heavy grades. Duplex grinding means the ring faces are flush-ground to a common height, so a like-marked partner ring seats against it and reaches the marked preload without shims.
Bore: 95 mm (3.7402 in)
Outside diameter: 145 mm (5.7087 in)
Width: 24 mm (0.9449 in)
Contact angle: 15°
Precision class: ABEC 7
Preload: light
Rolling elements: steel balls, single row
Closure: open both faces
1 Pc. One ring, half of a duplex light-preload pair.
ISO base number 7019, angle-designated 7019C. Searchable forms are EX95-7CE1DUL, EX957CE1DUL, EX 95 7 CE1 DUL and EX95 7CE1 DUL-1/2PR. An EX95-7CE2 or EX95-7CE3 ring carries a different contact angle on the same envelope and is a related size, not an interchange; DUM and DUH are the medium and heavy preload grades and are likewise related sizes.
