Timing Belt Pulleys and V-Belt Sheaves: Matching Belt Drive Components Correctly
Belt drives may appear simple, consisting of two wheels and a belt for power transfer.
Availability:
2 in stock
Sealed hybrid super-precision angular contact ball bearing, 30 x 55 x 13 mm, 15°, ceramic balls, SKF E high-speed design. Matched back-to-back (DB) pair.
List Price
$221.83
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | S7006 CE/HCDBG2VK353 |
| GTIN | 7316574794935 |
| Model | S 7006C E / HCDBG2VK353 |
| Bearing Type | Angular Contact Ball Bearing |
| ID | 30 mm |
| OD | 55 mm |
| Width | 13 mm |
| Total Width | 26 mm (pair) |
|---|---|
| Arrangement Configuration | Matched pair, back-to-back |
| Additional Attributes | Hybrid: silicon nitride ceramic balls; SKF E high-speed design; GTIN 7316574794935 |
| Contact Angle | 15° |
| Mounting Arrangement | Back-to-back (DB) |
| Industry Terms | hybrid angular contact bearing; ceramic ball spindle bearing; sealed super precision bearing; matched DB pair; 7006 angular contact |
| Common Misspellings | SKF S7006CE HCDBG2VK353; SKF S 7006 CE HC DB; SFK S7006 CE/HCDBG2VK353 |
| Application Types | Machine tool spindles; high-speed precision spindles |
| Mpn Variants | S7006 CE/HCDBG2VK353; S7006CE/HCDBG2VK353; S7006 CE HCDBG2VK353; S7006CE |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Closure Type | Non-contact seals both sides |
SKF S7006 CE/HCDBG2VK353 is a sealed, hybrid, super-precision angular contact ball bearing of SKF’s high-speed E design, in the ISO 70 dimension series, matched as a back-to-back pair. Unit Quantity: 2 Pcs. Rolling Elements: ceramic balls (silicon nitride). Closure Type: non-contact seals both sides. GTIN: 7316574794935.
S — sealed execution, non-contact seals on both sides.
7006 — ISO 70 extra-light dimension series, bore code 06, 30 x 55 x 13 mm.
CE — 15° contact angle, SKF high-speed E design.
HC — hybrid bearing: bearing steel rings with silicon nitride ceramic balls.
DB — matched set of two bearings arranged back-to-back.
Contact Angle: 15°. Number Of Rows: 1 per bearing. Bore Type: Straight. Rolling Elements: ceramic balls (silicon nitride). Closure Type: non-contact seals both sides. Mounting Arrangement: back-to-back (DB). Design: SKF E high-speed. GTIN: 7316574794935.
Bore Diameter: 30 mm. Outside Diameter: 55 mm. Overall Width: 13 mm per bearing. Total Width: 26 mm across the pair.
Bore 30 mm, outside diameter 55 mm, width 13 mm per bearing; total width 26 mm across the back-to-back pair.
CE is a 15° contact angle in SKF’s high-speed E design; HC is a hybrid execution with silicon nitride ceramic balls.
A matched back-to-back (DB) pair, 2 pieces, sealed with non-contact seals on both sides.
