Deep Groove Ball Bearings: The Industry Default and When to Reach for Something Else
If you pulled a bearing off general industrial equipment at random, there’s a good chance
Availability:
1 in stock
Angular contact ball bearing, 70 x 125 x 24 mm, 40° contact angle, pressed brass cage, single row. SKF 7214 BEY in the 72 light series, 70 mm bore, open.
List Price
$136.17
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7214 BEY |
| Model | 7214-BEY |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 70 mm |
| OD | 125 mm |
| Width | 24 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Mpn Variants | 7214 BEY, 7214BEY, 7214-BEY, 7214B |
| Rolling Elements | Ball |
| Cage Material | Pressed brass |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50.68 |
| Contact Angle | 40° |
| Bearing Material | Bearing steel |
| Closure Type | Open |
| Cross Reference 1 | SKF 7214 BECBY - Explorer class, universal matching |
|---|---|
| Cross Reference 2 | FAG 7214-B-XL-MP - machined brass cage |
| Cross Reference 4 | NTN 7214B |
SKF 7214 BEY is a single row angular contact ball bearing with a 40° contact angle and a pressed brass cage, 70 x 125 x 24 mm, open. Sold as 1 piece.
72 — ISO dimension series 02, light section.
14 — bore code, 70 mm bore, giving the 70 x 125 x 24 mm envelope.
B — 40° contact angle.
E — SKF optimised internal design.
Y — pressed brass window cage, ball centred.
Bore Diameter: 70 mm. Outside Diameter: 125 mm. Overall Width: 24 mm. Contact Angle: 40°. Number Of Rows: 1. Rolling Elements: Ball. Cage Material: Pressed brass. Closure Type: Open. Bore Type: Straight. Bearing Material: Bearing steel. Series: 72. Unit Quantity: 1 Pc. The 40° contact angle gives high axial load capacity in one direction alongside radial load; two bearings mounted as a pair take axial load in both directions.
Envelope: 70 mm bore, 125 mm outside diameter, 24 mm width. Single bearing, thrust in one direction.
SKF 7214 BECBY is the SKF Explorer execution, universal matching, pressed brass cage, same envelope and 40° angle. FAG 7214-B-XL-MP has a machined brass cage. NTN 7214B is 40° in the same envelope. Searchable forms: 7214 BEY, 7214BEY, 7214-BEY, 7214B.
70 mm bore, 125 mm outside diameter, 24 mm width.
40°, code B.
A pressed brass window cage, ball centred (code Y).
