SKF 7015-C/P4 single-row angular contact ball bearing, 75 x 115 x 20 mm, 15° contact angle, ABEC 7 / P4 precision, open, straight bore, bearing steel.
List Price
$129.06
3 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7015-C/P4 |
| Model | 7015CP4 |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 75 mm |
| OD | 115 mm |
| Width | 20 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Precision Class | ABEC 7 / P4 |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Bearing Material | Bearing Steel |
| Industry Terms | Angular contact bearing; precision angular contact; P4 angular contact; 15 degree angular contact bearing |
| Common Misspellings | SKF 7015 C P4; SKF7015-C/P4; SFK 7015-C/P4; SKF 7015CP-4 |
| Application Types | Machine tool spindles; precision spindles |
| Mpn Variants | 7015-C/P4; 7015CP4; 7015 C P4; 7015C; SKF 7015-C/P4 |
| Closure Type | Open |
| Cross Reference 1 | Timken 2MM9115WICR - 15 deg |
|---|
SKF 7015-C/P4 single-row angular contact ball bearing, 75 x 115 x 20 mm, 15° contact angle, ABEC 7 / P4 precision, open, straight bore. Unit Quantity: 1 Pc.
7015 — 70 series angular contact ball bearing; bore code 15, multiplied by five to give a 75 mm bore.
C — 15° contact angle.
P4 — ISO P4 precision class, equal to ABEC 7.
Bore Diameter: 75 mm. Outside Diameter: 115 mm. Overall Width: 20 mm. Bore Type: straight. Contact Angle: 15°. Precision Class: ABEC 7 / P4. Closure Type: open. Rolling Elements: ball. Number Of Rows: 1. Series: 7000. Bearing Material: bearing steel.
Bore Diameter: 75 mm. Outside Diameter: 115 mm. Overall Width: 20 mm.
Cross-Reference 1: Timken 2MM9115WICR, 15° contact angle. Searchable variants of the number: 7015-C/P4, 7015CP4, 7015 C P4, 7015C.
Bore 75 mm, outside diameter 115 mm and width 20 mm.
The C in the designation is a 15° contact angle. P4 is ISO P4 precision, equal to ABEC 7.
It is the 70 series angular contact size with bore code 15, a 75 mm bore.
