Super-precision angular contact ball bearing, 45 x 75 x 16 mm, 15° contact angle, P4A, extra light preload GA. High-speed E design, universally matchable.
List Price
$179.34
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | SKF |
|---|---|
| MPN | 7009 CEGA/P4A |
| Model | 7009CEGA/P4A |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 45 mm |
| OD | 75 mm |
| Width | 16 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7000 |
| Preload | Extra light when paired (GA) |
| Arrangement Configuration | Single bearing, universally matchable for extra light preload |
| Precision Class | ABEC 7 / P4A |
| Additional Attributes | eCl@ss 23-05-08-04; UNSPSC 31171531; indicative carbon footprint 0.87 kg CO2e |
| Cage Type | Outer-ring shoulder-guided |
| Dynamic Load Rating | 13,000 N |
| Static Load Rating | 8,500 N |
| Precision Rating | ABEC 7 / P4A |
| Rolling Elements | Ball |
| Item Weight | 0.234 kg (0.52 lb) |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Universally matchable (DB, DF or DT) |
| Bearing Material | Bearing steel |
| Industry Terms | super precision angular contact bearing; universally matchable angular contact bearing; machine tool spindle bearing; P4A spindle bearing; 45 mm bore 15 degree angular contact bearing |
| Common Misspellings | SKF 7009 CEGA/P4; SFK 7009 CEGA/P4A; SKF 7009 CGEA/P4A; SKF 7009CEGA P4A; SKF 7009 CE/GA/P4A |
| Application Types | Machine tool spindles; high-speed precision spindles; precision rotary tables |
| Mpn Variants | 7009 CEGA/P4A; 7009CEGA/P4A; 7009 CE GA P4A; 7009CEGAP4A; 7009 CEGA P4A |
| Closure Type | Open |
| Cross Reference 1 | RHP 7009CTRSULP4 – 15°, light preload (GA is extra light) |
|---|---|
| Cross Reference 2 | FAG B7009-C-T-P4S-UL – 15°, light preload (GA is extra light) |
| Cross Reference 3 | NSK 7009CTYNSULP4 – 15°, light preload (GA is extra light) |
| Cross Reference 4 | NTN 7009UCG/GLP4 – 15°, light preload (GA is extra light) |
| Cross Reference 5 | Koyo 7009C-5GLFGP4 – 15°, light preload (GA is extra light) |
SKF 7009 CEGA/P4A is a single-row super-precision angular contact ball bearing, 45 x 75 x 16 mm, with a 15° contact angle. It is the SKF high-speed E design in tolerance class P4A, universally matchable, supplied as one bearing (Unit Quantity: 1 Pc) and not as a factory-matched set.
7009 — ISO 70 dimension series, bore code 09: 45 mm bore, 75 mm outside diameter, 16 mm width.
C — 15° contact angle.
E — SKF high-speed E design.
GA — universally matchable single bearing ground to measuring load class A; two GA bearings form an extra light preloaded pair.
P4A — SKF super-precision tolerance class P4A, ABEC 7.
Bore Diameter: 45 mm. Outside Diameter: 75 mm. Overall Width: 16 mm. Contact Angle: 15°. Dynamic Load Rating: 13,000 N. Static Load Rating: 8,500 N. Both ratings are single-bearing ratings. Precision Class: ABEC 7 / P4A. Preload: Extra light when paired (GA). Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Seal Type: Open. Bearing Material: Bearing steel. Cage Type: Outer-ring shoulder-guided. Lubricant: None. Item Weight: 0.234 kg (0.52 lb). Harmonization Code: 8482.10.50. Unit Quantity: 1 Pc.
Envelope: 45 mm bore, 75 mm outside diameter, 16 mm width. Mounting Arrangement: universally matchable, back-to-back (DB), face-to-face (DF) or tandem (DT). Contact type: normal contact, two-point. Ring type: one-piece inner and outer rings. Axial load acts in one direction on a single bearing.
Other 45 x 75 x 16 mm, 15° super-precision executions: RHP 7009CTRSULP4, FAG B7009-C-T-P4S-UL, NSK 7009CTYNSULP4, NTN 7009UCG/GLP4 and Koyo 7009C-5GLFGP4. The UL and GL suffixes denote light preload, one step above the SKF extra light GA.
Bore Diameter: 45 mm. Outside Diameter: 75 mm. Overall Width: 16 mm.
Contact Angle: 15° (letter C). Precision Class: SKF P4A, ABEC 7.
No. It is a single universally matchable bearing, Unit Quantity: 1 Pc. Two GA bearings form an extra light preloaded pair.
