SKF5205 ADouble Row Angular Contact Ball Bearing – 25 mm ID, 52 mm OD, 20.6 mm Width, Open, 30° contact angle.

Condition: New

Availability:

3 in stock

SKF 5205 A double row angular contact ball bearing, 25 x 52 x 20.6 mm, 30° contact angle, open, sheet metal cage, CN axial clearance. Metric designation 3205 A.

List Price

$39.99

3 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

3 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandSKF
MPN5205 A
Model3205-A 5205-A
Bearing TypeAngular Contact Ball Bearing, Open
ID25 mm
OD52 mm
Width20.6 mm

Technical Specifications

MaterialBearing Steel
Series5200
LubricantNone (supplied unlubricated)
Additional AttributesSheet metal cage; axial internal clearance CN; back-to-back (O) contact arrangement; one-piece rings
Dynamic Load Rating22 kN
Static Load Rating15.3 kN
Rolling ElementsBall
Item Weight0.172 kg
Cage MaterialSheet metal
Limiting Speed12000
Number Of Rows2
Bore TypeStraight
Snap Ring IncludedNo
Internal ClearanceCN (normal axial)
Harmonization Code8482.10.50
Contact Angle30°
Mounting ArrangementBack-to-back (O)
Bearing MaterialBearing steel
Closure TypeOpen
Industry Termsdouble row angular contact bearing; two-row angular contact ball bearing; 3205 A bearing; 5205 bearing; back-to-back double row bearing
Common MisspellingsSFK 5205A; SKF5205A; SKF 5025 A; SKF 3250 A; SKK 5205-A
Application TypesPumps; gearboxes; electric motors; compressors; general industrial machinery
Mpn Variants5205A; 5205-A; 5205 A; 3205A; 3205-A; 3205 A

Cross-References

Cross Reference 1SKF 3205 A - SKF metric designation
Seller Part Number: B-AI2B2#KR3YHZ

Product Description

What this part is:

SKF 5205 A is a double row angular contact ball bearing, new. Two rows of balls in a back-to-back (O) arrangement inside one-piece inner and outer rings, open on both sides. Bore Diameter: 25 mm. Outside Diameter: 52 mm. Width: 20.6 mm (13/16 in). Contact Angle: 30°. Sold as a single bearing, one-piece double row unit. Unit Quantity: 1 Pc.

Decoding the designation:

5205 — SKF/MRC US numbering for the ISO 3205 double row angular contact series, 25 mm bore, light (02) section. The metric catalogue designation for the same bearing is 3205 A.

A — standard internal design for this series, sheet metal cage.

Specifications:

Series: 5200. Number Of Rows: 2. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Cage Material: Sheet metal. Axial Internal Clearance: CN (normal). Bearing Material: Bearing steel. Mounting Arrangement: Back-to-back (O). Lubricant: None, supplied unlubricated. Relubrication Feature: Without. Item Weight: 0.172 kg.

Basic Dynamic Load Rating (C): 22 kN. Basic Static Load Rating (C0): 15.3 kN. Limiting Speed: 12,000 r/min.

Dimensions and mounting:

Bore Diameter: 25 mm. Outside Diameter: 52 mm. Overall Width: 20.6 mm (13/16 in). Arrangement of contact angle: back-to-back (O).

Compatibility and replacement:

SKF 3205 A — SKF metric designation of the same bearing.

MPN variants: 5205A, 5205-A, 3205-A, 3205 A.

Frequently asked questions:

What are the dimensions of the SKF 5205 A?

Bore Diameter: 25 mm. Outside Diameter: 52 mm. Width: 20.6 mm (13/16 in).

What is the SKF metric designation for the 5205 A?

3205 A.

What contact angle and cage does it have?

Contact Angle: 30°. Cage Material: Sheet metal.
