NTN7311T1Angular Contact Ball Bearing — 55 mm ID, 120 mm OD, 29 mm Width, 30° Contact Angle, Phenolic Cage, Open

Condition: New – Open box
Condition Note: Made In Japan, New Old Stock

Availability:

2 in stock

NTN 7311T1 angular contact ball bearing, 55 x 120 x 29 mm, 30° contact angle, phenolic resin cage, single row, open. 73 medium series, radial and axial load.

List Price

$63.99

2 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

2 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandNTN
MPN7311T1
Model7311 T1
Bearing TypeAngular Contact Ball Bearing, Open
ID55 mm
OD120 mm
Width29 mm

Technical Specifications

Mpn Variants7311T1, 7311-T1, 7311 T1
Series7300
Rolling ElementsBall
Cage MaterialPhenolic
Number Of Rows1
Bore TypeStraight
Contact Angle30°
Closure TypeOpen

Cross-References

Cross Reference 1NSK 7311A (30°; cage differs)
Cross Reference 2Koyo 7311 (30°; cage differs)
Seller Part Number: AG6B5#7M4ZVQ

Product Description

What this part is:

NTN 7311T1 is a single-row angular contact ball bearing in the ISO 73 medium series with a 30° contact angle and a phenolic resin cage. It carries combined radial and single-direction axial load and is normally mounted opposed to a second bearing. Unit Quantity: 1 Pc.

Decoding the designation:

73 — angular contact ball bearing, ISO diameter series 3 (medium).

11 — bore code, 11 x 5 = 55 mm.

No angle letter — NTN standard 30° contact angle.

T1 — phenolic resin cage.

Specifications:

Bore Diameter: 55 mm. Outside Diameter: 120 mm. Overall Width: 29 mm. Contact Angle: 30°. Number Of Rows: 1. Rolling Elements: Ball. Bore Type: Straight. Closure Type: Open. Cage Material: Phenolic. Series: 7300.

Dimensions and mounting:

Chamfer r min: 2.0 mm. Chamfer r1 min: 1.0 mm.

Compatibility and replacement:

30° contact angle, 55 x 120 x 29 mm: NSK 7311A and Koyo 7311 (cage design differs). Searchable forms of the number: 7311T1, 7311-T1, 7311 T1.

Frequently asked questions:

What are the dimensions of the NTN 7311T1?

55 mm bore, 120 mm outside diameter, 29 mm width.

What is the contact angle?

30°, the NTN standard when the designation carries no angle letter.

What does T1 mean?

A phenolic resin cage.
