Central Surplus Bearing Finder
A faster way to search our bearing inventory Today we’re launching the Central Surplus Bearing
Availability:
1 in stock
Angular contact ball bearing, 35 mm bore x 80 mm OD x 21 mm wide, 30° contact angle, phenolic cage, universal flush-ground, light preload. NTN 7307T1GGLPX1.
List Price
$42.48
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NTN |
|---|---|
| MPN | 7307T1GGLPX1 |
| Model | 7307 T1 G GL PX1 7307 SUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 35 mm |
| OD | 80 mm |
| Width | 21 mm |
| Series | 7300 |
|---|---|
| Material | Bearing Steel |
| Precision Class | PX1 (NTN special tolerance) |
| Rolling Elements | Ball |
| Cage Material | Phenolic |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.1 |
| Contact Angle | 30° |
| Preload | Light |
| Mounting Arrangement | Universal (single flush-ground) |
| Industry Terms | 7307 angular contact bearing; 35x80x21 bearing; universal flush ground angular contact bearing; 30 degree angular contact ball bearing |
| Common Misspellings | 7307 T1GGLPX1; NTN7307T1GGLPX1; 7307T1GGL PX1; 7307-T1GGLPX1 |
| Application Types | Machine tool spindles; pumps; gearboxes; general industrial machinery |
| Mpn Variants | 7307T1GGLPX1, 7307-T1-G-GL-PX1, 7307 T1 G GL PX1, 7307 SUL |
| Cross Reference 1 | NSK 7307A - 30 deg, not universal flush-ground |
|---|---|
| Cross Reference 2 | Koyo 7307 - 30 deg, not universal flush-ground |
NTN 7307T1GGLPX1 is a single-row angular contact ball bearing, single flush-ground for universal matching, with a phenolic cage and light preload.
7307 — 73 medium series angular contact ball bearing; bore code 07 = 35 mm bore. No angle letter = 30° contact angle.
T1 — phenolic resin cage.
G — single bearing with flush-ground faces for universal matching in back-to-back, face-to-face or tandem sets.
GL — light preload when paired.
PX1 — NTN special tolerance class.
Bore Diameter: 35 mm. Outside Diameter: 80 mm. Overall Width: 21 mm. Contact Angle: 30°. Cage Material: Phenolic. Preload: Light. Mounting Arrangement: Universal (single flush-ground). Closure Type: Open. Rolling Elements: Ball. Number Of Rows: 1. Bore Type: Straight. Series: 7300. Precision Class: PX1 (NTN special tolerance). Unit Quantity: 1 Pc.
The 35 x 80 x 21 mm envelope fits shaft seats and housings machined for a 7307. The 30° angle carries combined radial load and axial load in one direction. Flush-ground faces allow two or more bearings to be set up as a matched pair or set with a light preload.
Cross-references: NSK 7307A (30°, not universal flush-ground) and Koyo 7307 (30°, not universal flush-ground). Both are angular contact bearings in the 35 x 80 x 21 mm envelope with standard grinding. The 7307 SUL marking is the single universal-ground, light preload form.
35 mm bore, 80 mm outside diameter and 21 mm width.
30 degrees.
Light preload when paired.
