Availability:
1 in stock
Single 15° super-precision spindle bearing, 80 mm bore x 140 mm OD x 26 mm wide, P4S tolerance with a phenolic cage and light preload, universally ground so it can be stacked into a matched set — for high-speed machine tool spindles. One bearing.
List Price
$114.69
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| Model | B7216C B T P4S UL / 216 H C / 2MM216 / 7216 CT Y |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 80 mm |
| OD | 140 mm |
| Width | 26 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7200 |
| Base Number | 7216 |
| Industry Terms | Spindle bearing, machine tool bearing, super precision angular contact, universally ground single, precision ball bearing |
| Common Misspellings | F.A.G., FAG B7216CB T P4S UI, B7216C.T.P45.UL, B7216CBTP4SUI, B72I6C |
| Application Types | Machine tool spindles, grinding spindles, high-speed rotary tables, precision gearboxes |
| Bore Shaft Size | 80 mm |
| Mpn Variants | B7216C.T.P4S.UL, B7216CB.T.P4S.UL, B7216CBTP4SUL, B-7216-C-T-P4S-UL, B7216-C-T-P4S-UL |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50.68 |
| Part Number | B7216C.T.P4S.UL |
A single FAG B7216 super-precision angular contact ball bearing: 80 mm bore, 140 mm OD, 26 mm wide, 15° contact angle, phenolic cage, P4S tolerance class, universally ground for light preload. The B prefix is FAG’s spindle-bearing line — parts built specifically for machine tool spindles, grinding heads, high-speed rotary tables and precision gearboxes rather than for general industrial duty.
B — FAG super-precision spindle bearing series.
7216 — ISO angular contact envelope, light series, 80 x 140 x 26 mm.
C — 15° contact angle.
T — phenolic (fabric-laminate) cage.
P4S — FAG super-precision class: P4 dimensional tolerance with tightened running accuracy.
UL — universally ground, light preload.
15° is the speed-biased end of the angular contact range: high radial capacity and a high speed ceiling, less thrust capacity and axial stiffness than a 25° bearing of the same size. Light preload keeps friction and heat generation low, which is what allows those speeds and gives long grease life. The phenolic cage is light, quiet and self-lubricating at speed but must be kept away from solvents, steam and sustained high temperature. P4S accuracy only reaches the workpiece if the shaft and housing seats are ground to a comparable class — fitted into an ordinary bore, a P4S bearing performs like a standard one.
Bore: 80 mm.
Outside diameter: 140 mm.
Width: 26 mm.
Contact angle: 15°.
Tolerance class: P4S.
Preload: light (UL).
Cage: phenolic.
Series: FAG B7200 spindle bearing, 7216 envelope.
Rows: single.
Closure: open.
One bearing. Universally ground rings mean this bearing can be run on its own or combined with identical bearings back-to-back (DB), face-to-face (DF) or in tandem (DT), and the ground offsets will produce the intended light preload without a ground spacer. Order the number of pieces the spindle arrangement calls for.
Direct equivalents are 7216-envelope 15° super-precision universally ground light-preload singles: FAG B7216-C-T-P4S-UL, the Fafnir 2MM216WI-CR-SUL and NSK 7216CTYSULP4. Related but NOT interchangeable: B7216-E-T-P4S-UL is the same envelope at 25°, UM and UO denote medium preload and universal with no preload, and a plain 7216 without the B prefix is a standard-class industrial bearing rather than a spindle bearing.
$231.30
29 in stock
