FAG B7018C.TPA.P4.UL super precision angular contact spindle bearing, 90 x 140 x 24 mm, 15° contact angle, P4, phenolic cage, universal, light preload.
List Price
$305.99
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| Model | B7018-C-TPA-P4-UL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 90 mm |
| OD | 140 mm |
| Width | 24 mm |
| Series | B70 |
|---|---|
| Lubricant | Oil/Grease |
| Preload | Light |
| Mpn Variants | B7018C.TPA.P4.UL, B7018-C-TPA-P4-UL, B7018C, B-7018-C-TPA-P4-UL |
| Compatible With Replaces | Successor: FAG B7018-C-T-P4S-UL |
| Precision Class | ABEC 7 / P4 |
| Additional Attributes | Successor B7018-C-T-P4S-UL data: Dynamic load rating 78,000 N; Static load rating 51,000 N; Limiting speed oil 15,000 rpm; Operating temperature -30 to 100 °C; Axial rigidity L/M/H 95 / 161 / 229 N/µm; Lift-off force L/M/H 1,347 / 4,651 / 9,920 N; Shaft shoulder diameter da 100 mm |
| Rolling Elements | Ball |
| Cage Material | Phenolic (laminated fabric) |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal (single bearing, any arrangement) |
| Cross Reference 1 | FAG B7018-C-T-P4S-UL (successor) |
|---|---|
| Cross Reference 2 | SKF 7018 CD/P4A |
| Cross Reference 3 | NSK 7018CTRSULP4 |
| Cross Reference 4 | Fafnir 2MM9118WI SUL |
FAG B7018C.TPA.P4.UL is a super precision spindle bearing, single row angular contact, in the B70 series. Bore Diameter: 90 mm. Outside Diameter: 140 mm. Overall Width: 24 mm. Contact Angle: 15°. Precision Class: P4. Preload: Light.
B — FAG standard spindle bearing design with steel balls.
70 — ISO 70 dimension series.
18 — bore code, 90 mm.
C — 15° contact angle.
TPA — fabric-base laminated phenolic cage.
P4 — ISO P4 tolerance class.
U — universal single bearing, mounts in any arrangement.
L — light preload.
Cage Material: Phenolic (laminated fabric). Closure Type: Open. Mounting Arrangement: Universal. Successor B7018-C-T-P4S-UL data: Dynamic Load Rating 78,000 N; Static Load Rating 51,000 N; Limiting speed, oil 15,000 rpm; operating temperature -30 to 100 °C; axial rigidity at light preload 95 N/µm; lift-off force at light preload 1,347 N.
Successor B7018-C-T-P4S-UL data: shaft shoulder diameter da 100 mm.
Current Schaeffler designation: FAG B7018-C-T-P4S-UL. 15° angle, light preload: SKF 7018 CD/P4A, NSK 7018CTRSULP4, Fafnir 2MM9118WI SUL.
