Availability:
1 in stock
FAG 6215-2Z-C3 deep groove ball bearing, 75 x 130 x 25 mm, steel shields both sides, C3 clearance. Cr 70,000 N, C0r 49,000 N, 6,600 rpm limiting speed.
List Price
$44.11
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | FAG |
|---|---|
| MPN | 6215-2Z-C3 |
| Model | 6215.2Z.C3 |
| Bearing Type | Ball Bearing, Shields both sides (2Z) |
| ID | 75 mm |
| OD | 130 mm |
| Width | 25 mm |
| Series | 62 |
|---|---|
| Lubricant | Grease |
| Min Temp | -20 °C |
| Dynamic Load Rating | 70,000 N |
| Static Load Rating | 49,000 N |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 1.21 kg (2.67 lb) |
| Cage Material | Pressed steel |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Limiting Speed | 6,600 rpm |
| Harmonization Code | 8482.10 |
| Internal Clearance | C3 |
| Industry Terms | deep groove ball bearing, shielded ball bearing, ZZ bearing, electric motor bearing, C3 clearance |
| Overall Width | 25 mm |
| Mpn Variants | 6215-2Z-C3, 62152ZC3, 6215.2Z.C3, 6215 2Z C3, 6215ZZC3, 6215.2ZR.C3 |
| Compatible With Replaces | Replaces FAG 6215.2Z.C3, 6215.2ZR.C3 |
| Precision Class | ABEC 1 / P0 |
| Additional Attributes | Fatigue limit load Cu: 3,300 N; Reference speed: 5,900 rpm; r min: 1.5 mm; da min: 84 mm; Da max: 121 mm |
| Common Misspellings | FAG 6215-2ZC3, FAG6215-2Z-C3, Fag 6215 2z c3, FAG 6215-ZZ-C3 |
| Application Types | Electric motors; pumps; gearboxes; general industrial machinery |
| Cross Reference 1 | SKF 6215-2Z/C3 |
|---|---|
| Cross Reference 2 | NTN 6215ZZC3 |
| Cross Reference 3 | NSK 6215ZZC3 |
| Cross Reference 4 | Koyo 6215ZZC3 |
| Cross Reference 5 | Timken 6215-ZZ-C3 |
FAG 6215-2Z-C3 is a single-row deep groove ball bearing with steel shields on both sides, a pressed steel cage and C3 radial internal clearance. Unit Quantity: 1 Pc.
6215 — ISO 62 series deep groove ball bearing, bore code 15 = 75 mm.
2Z — sheet steel shields on both sides.
C3 — radial internal clearance larger than normal.
Bore Diameter: 75 mm. Outside Diameter: 130 mm. Overall Width: 25 mm. Closure Type: Shields both sides. Internal Clearance: C3. Cage Material: Pressed steel.
Dynamic Load Rating: 70,000 N. Static Load Rating: 49,000 N. Fatigue Limit Load: 3,300 N. Limiting Speed: 6,600 rpm. Reference Speed: 5,900 rpm. Operating Temperature: -20 °C to 120 °C. Item Weight: 1.21 kg (2.67 lb).
Chamfer r min: 1.5 mm. Fillet ra max: 1.5 mm. Shaft Abutment da min: 84 mm. Housing Abutment Da max: 121 mm.
Cross-references: SKF 6215-2Z/C3, NTN 6215ZZC3, NSK 6215ZZC3, Koyo 6215ZZC3, Timken 6215-ZZ-C3. Replaces FAG 6215.2Z.C3 and 6215.2ZR.C3.
Bore Diameter: 75 mm. Outside Diameter: 130 mm. Overall Width: 25 mm.
Steel shields on both sides and C3 radial internal clearance.
Dynamic Load Rating: 70,000 N. Static Load Rating: 49,000 N. Limiting Speed: 6,600 rpm.
