Angular Contact Ball Bearing — 100 mm ID, 215 mm OD, 47 mm Width, 30° Contact Angle, ABEC 7, Heavy Preload, Open$531.11
Super-Precision Angular Contact Ball Bearing - Straight Bore, 100 mm ID, 150 mm OD, 24 mm Width, Open, 25° Contact Angle, Medium Preload, Phenolic Cage.$141.97
Super Precision Angular Contact Ball Bearing - Straight Bore, 100 mm ID, 150 mm OD, 24 mm Width, Open, 15° Contact Angle, Light Preload, Universally Ground$346.83
Super Precision Angular Contact Ball Bearing - Straight Bore, 100 mm ID, 150 mm OD, 24 mm Width, Open, 25° Contact Angle, Phenolic Cage, Universal Heavy Preload, ABEC 7/9 P4S$346.83| MFR / Brand | Fafnir |
|---|---|
| MPN | 7320WO |
| Model | 7320WODU |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 100 mm |
| OD | 215 mm |
| Width | 47 mm |
| Material | Bearing Steel |
|---|---|
| Series | 7300 |
| Condition | New – Open box |
| Lubricant | Oil/Grease |
| Running Accuracy | P0 |
| Condition Note | Made In USA, Brass Cage. |
| Min Temp | -30 °C |
| Cage Type | Machined Brass |
| Dynamic Load Rating | 217 kN / 49000 lbf |
| Static Load Rating | 177 kN / 40000 lbf |
| Precision Rating | ABEC 1 / P0 |
| Rolling Elements | Ball |
| Max Temp | 120 °C |
| Item Weight | 18.2 lbs |
| Cage Material | Brass |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50 |
| Contact Angle | 40° |
| Mounting Arrangement | Universal |
| Limiting Speed | 3200 rpm |
| Cross Reference 1 | SKF 7320 BCM |
|---|---|
| Cross Reference 2 | NTN 7320 |
FAFNIR 7320WO Angular Contact Bearing Experience unmatched performance and reliability with the FAFNIR 7320WO Angular Contact Bearing. Meticulously crafted in the USA, this bearing measures 100x215x47 mm, making it a perfect choice for various industrial applications. The model 7320WO, available in a new open box condition, is engineered to provide dynamic support for high axial and radial loads, ensuring exceptional durability and precision for your machinery. Key Features: Model: 7320WODU Type: Angular Contact Ball Bearing Origin: United States Whether you are replacing an existing bearing or outfitting new machinery, the FAFNIR 7320WO is specifically designed to enhance your operational capabilities with seamless reliability. Its robust design allows it to perform under demanding conditions, making it an essential part of your equipment maintenance strategy. Additional Information: We buy your surplus bearings; contact us for inquiries. Enjoy international shipping, with combined shipping options on multiple orders. Same-day or next-day shipping available for added convenience. Trust FAFNIR for all your bearing needs and elevate your projects with quality you can count on. Order your FAFNIR 7320WO Angular Contact Bearing today!
