AXIS 7206CTBP4DUL angular contact ball bearing, 30 mm bore, 62 mm OD, 16 mm width, 15 degree contact angle, P4 precision, universal matching with light preload.
List Price
$43.72
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | AXIS |
|---|---|
| MPN | 7206CTBP4DUL |
| Model | 7206-C-TB-P4-DUL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 30 mm |
| OD | 62 mm |
| Width | 16 mm |
| Series | 72 |
|---|---|
| Preload | Light |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Ball |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.50.28 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal (DB, DF or DT) |
| Base Number | 7206 |
| Overall Width | 16 mm |
| Mpn Variants | 7206CTBP4DUL, 7206-C-TB-P4-DUL, 7206C TB P4 DUL |
| Precision Class | ABEC 7 / P4 |
| Closure Type | Open |
| Cross Reference 1 | SKF 7206 CD/P4A |
|---|---|
| Cross Reference 2 | FAG B7206-C-T-P4S |
| Cross Reference 3 | NSK 7206CTYNSULP4 |
| Cross Reference 4 | Timken 2MM206WI |
AXIS 7206CTBP4DUL is a single-row angular contact ball bearing in the ISO 7206 envelope, 30 x 62 x 16 mm, with a 15° contact angle, P4 precision and universal matching with light preload.
72 — ISO 02 dimension series angular contact ball bearing.
06 — bore code, 06 x 5 = 30 mm.
C — 15° contact angle.
P4 — ISO P4 precision, equivalent to ABEC 7.
DUL — universally matchable for paired mounting, light preload.
Bore Diameter: 30 mm. Outside Diameter: 62 mm. Overall Width: 16 mm. Contact Angle: 15°. Precision Class: ABEC 7 / P4. Preload: Light. Mounting Arrangement: Universal (DB, DF or DT). Rolling Elements: Ball. Number Of Rows: 1. Closure Type: Open.
Envelope: 30 x 62 x 16 mm. Universal matching allows back-to-back, face-to-face or tandem arrangement with another DU bearing of the same designation.
Same envelope, 15° angle and P4 class: SKF 7206 CD/P4A, FAG B7206-C-T-P4S, NSK 7206CTYNSULP4 and Timken 2MM206WI. MPN variants: 7206CTBP4DUL, 7206-C-TB-P4-DUL, 7206C TB P4 DUL.
15°, from the C in the designation.
ISO P4, equivalent to ABEC 7.
Bore Diameter: 30 mm. Outside Diameter: 62 mm. Width: 16 mm.
