This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing - 65 mm ID, 100 mm OD, 18 mm Width, Open, 15°, PEEK Cage to 250°C, ABEC 7$52.49
Super Precision Angular Contact Ball Bearing - 65 mm ID, 100 mm OD, 18 mm Width, Open, Light Preload, Machined Phenolic Cage, P4 / EP7$67.31
Angular Contact Ball Bearing - 65 mm ID, 100 mm OD, 18 mm Width, Open, 15°, Light Preload, PEEK Cage to 250°C, ABEC 7$73.62
Super-Precision Angular Contact Ball Bearing - 65 mm ID, 100 mm OD, 18 mm Width, Open, Phenolic Outer-Land-Riding Cage, Light Preload, ABEC 7$73.69| MFR / Brand | SNFA |
|---|---|
| MPN | EX65-7CE1DUM |
| Model | 2MM-9113 DUM / 7013C P4 DUM / EX 65-7 CE 1 DUM |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 65 mm |
| OD | 100 mm |
| Width | 18 mm |
| Material | Bearing Steel |
|---|---|
| Series | EX Series |
| Lubricant | Oil/Grease |
| Preload | Medium |
| Closure Type | Open |
| Cage Type | Phenolic Cage |
| Dynamic Load Rating | 38.5 kN / 8655 lbf |
| Static Load Rating | 35.5 kN / 7980 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Balls |
| Item Weight | 1.15 lbs |
| Cage Material | Phenolic |
| Limiting Speed | 21000 rpm |
| Bore Type | Straight |
| Snap Ring Included | Without Snap Ring |
| Harmonization Code | 8482.10.5028 |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Running Accuracy | P4 |
| Running Accuracy Radial And Axial Runout | P4 |
| Cross Reference 1 | SKF 71913 CD/P4ADGB |
|---|---|
| Cross Reference 2 | FAG B71913-C-T-P4S-DUM |
SNFA EX65-7CE1DUM Bearing – Precision Engineered for Optimal Performance
Upgrade your machinery with the SNFA EX65-7CE1DUM Bearing, a premium Angular Contact Ball Bearing meticulously crafted for industrial applications. With precise dimensions of 65 mm bore diameter, 100 mm outside diameter, and 18 mm width, this robust bearing ensures efficient performance and longevity.
Manufactured in the United Kingdom by the renowned brand SNFA, this bearing is made of high-quality steel, contributing to its reliability and durability. It is specifically designed to handle demanding conditions in mechanical power transmission and automation systems, making it an essential component for your operations.
Included in a practical UK 2 Pcs pack, the SNFA EX65-7CE1DUM Bearing is ideal for various applications, ensuring that you always have a spare for quick replacements. The advanced engineering and ABEC 7 precision rating underscore its capability to deliver superior performance.
Choose the SNFA EX65-7CE1DUM Bearing for your industrial needs and experience unmatched reliability and efficiency.
