This item is currently out of stock
Here are some other options that might fit your project — cross-referenced equivalents and similar parts we have in stock and ready to ship. Need help choosing? Call 585-295-7880.
Angular Contact Ball Bearing - 25 mm ID, 47 mm OD, 12 mm Width, Open, 15° Contact Angle, Light Preload.$44.30
Angular Contact Ball Bearing - 25 mm ID, 47 mm OD, 12 mm Width, Open, 15°, Light preload.$61.18
Angular Contact Ball Bearing - 25 mm ID, 47 mm OD, 12 mm Width, Open, 15° Contact Angle, Light Preload.$71.11
Angular Contact Ball Bearing - 25 mm ID, 47 mm OD, 12 mm Width, Open, 15° Contact Angle, ABEC 7 / P4 Precision$76.47| MFR / Brand | Koyo |
|---|---|
| MPN | 7005CGL |
| Model | 7005 C GL PA / 7005C T UL |
| Bearing Type | Angular Contact Ball Bearing, Open |
| ID | 25 mm |
| OD | 47 mm |
| Width | 12 mm |
| Series | 7000 |
|---|---|
| Condition | New – Open box |
| Lubricant | Oil |
| Preload | Light |
| Cage Type | Polyamide |
| Dynamic Load Rating | 15.4 kN / 3462 lbf |
| Static Load Rating | 8.0 kN / 1798 lbf |
| Precision Rating | ABEC 7 / P4 |
| Rolling Elements | Balls |
| Max Temp | 120°C |
| Item Weight | 0.18 lbs |
| Limiting Speed | 33000 rpm |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Snap Ring Included | No |
| Contact Angle | 15° |
| Mounting Arrangement | Universal |
| Cross Reference 1 | NSK 7005CTYNDULP4 |
|---|---|
| Cross Reference 2 | FAG B7005-E-T-P4S-UL |
| Cross Reference 3 | SKF 7005 CD/P4A |
| Cross Reference 4 | NTN 7005UCG/GLP4 |
Angular Contact Ball Bearing – 25 mm ID, 47 mm OD, 12 mm Width, Open, 15° Contact Angle, Light Preload
