AVENTICS R422101599 CO1 solenoid valve coil, 230 V AC 50/60 Hz, Form C ISO 15217 3-pin plug, 15 mm width, IP65, 100% duty cycle. Set of 2 pieces.
List Price
$28.90
2 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Aventics |
|---|---|
| MPN | R422101599 |
| Model | R-422-101-599 |
| Valve Operation | Solenoid |
|---|---|
| Coil Voltage | 230 V AC |
| Voltage | 230 V AC |
| Mpn Variants | R422101599, R-422-101-599, R 422 101 599 |
| Min Temp | -10 °C |
| Series | CO1 |
| Max Temp | 50 °C |
| Type | Solenoid Valve Coil |
| Ip Rating | IP65 |
| Item Weight | 0.022 kg |
| Housing Material | Polyamide |
| Industry Terms | Solenoid valve coil; 230 VAC valve coil; pneumatic valve solenoid coil; CO1 coil; Form C coil |
| Common Misspellings | Aventic R422101599, Aventis R422101599, R 422101599, R422 101 599, R4221O1599 |
| Application Types | Pneumatic valve control, automation equipment, packaging machinery, material handling |
AVENTICS R422101599 is a 230 V AC solenoid valve coil from the AVENTICS CO1 series, with a Form C plug connection. Each purchase is a set of 2 coils.
Series: CO1. Operational Voltage: 230 V AC at 50 Hz and 60 Hz. Voltage Tolerance: -10 % / +10 %. Holding Power: 1.6 VA at 50 Hz, 1.4 VA at 60 Hz. Switch-on Power: 2.2 VA at 50 Hz, 2 VA at 60 Hz. Duty Cycle: 100 % ED. Electrical Connection: Plug, Form C. Connector Standard: ISO 15217. Number of Poles: 3-pin. Protection Class: IP65 (EN 60529). Ambient Temperature: -10 °C to 50 °C. Housing Material: Polyamide. Weight: 0.022 kg. Unit Quantity: 2 Pcs.
Coil Width: 15 mm.
Part number formats: R422101599, R-422-101-599, R 422 101 599. AVENTICS product description: COIL KIT TC SERIES 230V AC FORM C.
CAD model and data sheet: available from Emerson AVENTICS (discreteautomation.emerson.com).
230 V AC, rated for both 50 Hz and 60 Hz, with a -10 % / +10 % tolerance.
A Form C 3-pin plug to ISO 15217, sealed to IP65.
Holding Power: 1.6 VA at 50 Hz and 1.4 VA at 60 Hz. Switch-on Power: 2.2 VA at 50 Hz and 2 VA at 60 Hz.
