Mitsubishi Q35B MELSEC-Q main base unit with 5 I/O module slots plus power supply and CPU slots, 0.11 A at 5 V DC, extendable, 245 x 98 x 44.1 mm.
List Price
$93.49
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Mitsubishi |
|---|---|
| MPN | Q35B |
| Model | Q35B |
| Industry Terms | PLC base unit; PLC backplane; PLC rack; main base |
|---|---|
| Common Misspellings | Q-35B; Q35-B; Q 35B |
| Item Width | 245 mm |
| Item Height | 98 mm |
| Item Length | 44.1 mm |
| Controller Platform | Mitsubishi MELSEC-Q |
| Mpn Variants | Q35B; Q-35-B; Q 35 B |
| Manufacturer Status | On sale (Commercialized) |
| Compatible With Replaces | MELSEC-Q series modules and power supplies; predecessor QA1S35B-E; extension cables QC05B, QC06B, QC12B, QC30B, QC50B, QC100B; Q6DIN2; QG60 |
| Additional Attributes | Number of mountable I/O modules: 5; Slots for power supply: 1; Possibility of extension: Extendable; Applicable module: MELSEC-Q series modules; Applicable power supply: MELSEC-Q series power supply module; Internal current consumption (5 V DC): 0.11 A; Mounting hole size: M4 screw hole or ø4.5 hole; DIN rail adapter: Q6DIN2 (sold separately); Conformance: UL, cUL, CE (EMC), CE (RoHS), KC (EMC), UKCA; Shipping approvals: LR, NK, DNV, ABS, RINA, BV; Europe order code: 127586; Global order code: 1W4E00 |
| Type | PLC Main Base Unit |
| Item Weight | 0.27 kg (0.60 lb) |
| Harmonization Code | 85381000 |
| Mounting Type | M4 screw; DIN rail with Q6DIN2 adapter |
Mitsubishi Electric Q35B main base unit (backplane) for the MELSEC-Q Series programmable controller. It carries one power supply slot, the CPU slot and 5 I/O module slots, and it is extendable with MELSEC-Q extension base units. Unit Quantity: 1 Pc.
Type: Main base unit. Series: MELSEC-Q Series. Number of mountable I/O modules: 5. Slots for power supply: 1. Possibility of extension: Extendable. Applicable module: MELSEC-Q series modules. Applicable power supply module: MELSEC-Q series power supply module. Internal current consumption (5 V DC): 0.11 A. Conformance standards: UL, cUL, CE (EMC), CE (RoHS), KC (EMC), UKCA. Shipping approvals: LR, NK, DNV, ABS, RINA, BV. Mitsubishi Electric Europe order code: 127586. Global order code: 1W4E00. Harmonization Code: 85381000.
Height: 98 mm. Width: 245 mm. Depth: 44.1 mm. Weight: 0.27 kg (0.60 lb). Mounting hole size: M4 screw hole or 4.5 mm hole (for M4 screw). DIN rail mounting adapter type: Q6DIN2.
Platform: Mitsubishi Electric MELSEC-Q Series. Predecessor listed by Mitsubishi Electric Europe: QA1S35B-E. Extension cables: QC05B, QC06B, QC12B, QC30B, QC50B, QC100B. Accessories: Q6DIN2 DIN rail mounting adapter, QG60 blank cover module.
5 I/O module slots, plus one power supply slot and the CPU slot.
Height: 98 mm. Width: 245 mm. Depth: 44.1 mm. Weight: 0.27 kg (0.60 lb).
DIN rail mounting adapter type: Q6DIN2. Extension cables: QC05B, QC06B, QC12B, QC30B, QC50B, QC100B.
