FANUCIC754GEN001-AAGenius Network Communication Option Card for QuickPanel View / Control HMI

Product Description

What this part is

A GE Fanuc IC754GEN001-AA Genius network communication option card for the QuickPanel View and QuickPanel Control operator-interface family. It is an expansion option card that installs into the option bay of a QuickPanel unit and gives that panel a Genius I/O bus port, so the HMI can talk directly to Genius-based PLCs, Genius I/O blocks and Genius bus controllers.

It is a communication option card, not the operator interface itself and not a display. There is no screen, no touch panel, no processor board and no enclosure in this listing — the card is useless on its own and must be fitted into a host QuickPanel.

Decoding the order code

IC – GE Fanuc Automation industrial controls prefix.754 – the QuickPanel View / QuickPanel Control product family. All IC754 numbers belong to that HMI platform; the panels themselves carry longer codes such as IC754VSI06CTD or IC754CGL06CTD that encode screen size, colour and technology.GEN – the option function, here Genius bus communication. GE Fanuc used matching short mnemonics for the other option cards in the same bay.001 – the specific option variant within that function.-AA – the hardware revision / issue level of the card. A revision suffix, not a different product; revisions of the same base number are normally interchangeable.

What these specs mean in practice

Genius is GE Fanuc’s legacy serial I/O bus, and it is not the same network as Ethernet, Profibus, DeviceNet or SNP serial. Fitting this card is the way to put a QuickPanel on an existing Genius bus without a protocol gateway. If your plant network is Ethernet or SNP, this is the wrong option card — check which network your bus controller uses before buying. The card is specific to the QuickPanel View / Control generation; it will not fit the earlier QuickPanel Junior or the later Emerson QuickPanel+ platforms.

What is not included

Option card only. This listing does not include a QuickPanel View or QuickPanel Control operator interface, the panel’s power supply or 24 V DC supply, the Genius bus cable or trunk terminating resistors, connector or terminal-block kits, mounting hardware or gaskets, a CompactFlash or memory card, Machine Edition / Proficy configuration software, a licence key, or any documentation or driver media. Genius bus wiring must be properly terminated at both trunk ends; those resistors are not supplied.

Quantity and configuration

Sold as 1 piece — one Genius option card. New old stock, in an opened box.

Installation and setup notes

Power down and isolate the QuickPanel before opening the option bay; the card is not hot-pluggable. Handle it by the edges with a wrist strap. After fitting, the Genius device must be given a bus address and configured in the panel’s project — the card does not communicate until the driver is configured and downloaded. Genius baud rate and address must match the rest of the bus, and no two devices may share an address.

Interchange guidance

Searchable equivalents of the same part number: IC754GEN001-AA, IC754GEN001AA, IC754-GEN001-AA, IC754 GEN 001 AA, IC754GEN001. Do not treat other IC754 option cards as interchanges — a different mnemonic in the code means a different network and a different physical port.

Correcting the source data

Earlier copy listed this as a plain Fanuc circuit board of Japanese manufacture. It is a GE Fanuc Automation QuickPanel Genius communication option card; the origin claim is not supported by the carton or by the manufacturer, so no country of origin is claimed here.
