RHPSFT1-9/16Two-Bolt Oval Flange Unit – 1-9/16 in Bore, Cast Iron, Set-Screw Locking

Condition: New – Open box
Condition Note: Made In England, New, No Box

Availability:

1 in stock

RHP SFT1-9/16 two-bolt oval flange bearing unit, 1-9/16 in bore, cast iron housing, set-screw locking, spherical insert, grease nipple. 1 Pc.

Same day shipment

List Price

$48.99

1 in stock

Prefer eBay? Buy this item on our store (opens in a new tab)

Small green outline icon of a shipping box with a clock, indicating delivery time
Availability

1 in stock

On the Shelf & Ready to Ship

Green shield badge reading "Same-Day Shipping" with box and delivery truck icons
Free US Shipping

Ships same day by 6pm ET

Green shield icon with box and arrow graphic labeled "Free Returns"
Free Returns

No Risk, No Hassle

Specifications

Key Specifications

MFR / BrandRHP
MPNSFT1-9/16
ModelSFT-1-9/16
ID1-9/16 in (39.6875 mm)

Technical Specifications

TypeTwo-Bolt Flange Bearing Unit
Industry TermsTwo-bolt flange unit, oval flange bearing, flanged housed unit, Self-Lube flange
Application TypesConveyors, fans, agricultural machinery, plate-mounted shafting
Bore Shaft Size1-9/16 in (39.6875 mm)
Housing StyleTwo-Bolt Oval Flange
Locking MethodTwo Knurled Cup-Point Set Screws
Replacement InsertRHP 1000G series
Mpn VariantsSFT1-9/16, SFT 1-9/16, SFT-1-9/16, SFT1.9/16, SFT1 9/16
MaterialCast Iron Housing, Through-Hardened Steel Insert
Min Temp-20 C
Cage TypeTwo-piece riveted metal cage
SeriesSFT (Self-Lube, Normal Duty)
Rolling ElementsBall
Max Temp110 C
Bearing TypeMounted Ball Bearing Flange Unit
Cage MaterialPressed Steel
Number Of Rows1
LubricantGrease
Insert Outer RingSpherical
Housing MaterialCast Iron
Part NumberSFT1-9/16
Mounting TypeTwo-Bolt Flange Mount
Additional AttributesInsert series RHP 1000G; spherical outer ring seating; through-hardened steel rings; super-finished raceways; nitrile single lip seal; grease nipple in housing; mineral oil / lithium soap grease
Common MisspellingsRPH SFT1-9/16; RHP SFT 1 9/16; RHP SFT1-9-16; RHP SFT 1.9/16; RHP SFTI-9/16
Seller Part Number: AI6B2#Q32DF8

Product Description

What this part is:

RHP Self-Lube SFT1-9/16 mounted ball bearing flange unit: cast iron two-bolt oval flange housing, 1-9/16 in (39.6875 mm) bore, set-screw locking, spherical-seating insert, single lip seal, grease nipple. Unit Quantity: 1 Pc.

Decoding the designation:

SFT — RHP Self-Lube normal-duty cast iron two-bolt oval flange unit, bore range 12 to 60 mm and 1/2 to 2-7/16 in.

1-9/16 — shaft size in inches, 39.6875 mm.

Specifications:

Housing Style: Two-Bolt Oval Flange. Bolt Count: 2. Housing Material: Cast Iron. Bore / Shaft Size: 1-9/16 in (39.6875 mm). Locking Method: Two knurled cup-point set screws in the extended inner ring. Series: SFT (Self-Lube, Normal Duty). Insert Series: RHP 1000G. Rolling Elements: Ball. Number Of Rows: 1. Cage Type: Two-piece riveted metal cage. Cage Material: Pressed Steel. Seal Type: Single lip seal, nitrile rubber lip bonded to a steel pressing secured in the outer ring. Insert Outer Ring: Spherical seating. Lubricant: grease. Relubrication: grease nipple fitted to the housing. Operating Temperature Range: −20 to +110 °C on the standard mineral oil / lithium soap grease. Country of Origin: United Kingdom.

Inner and outer rings are through-hardened steel with super-finished raceways.

Dimensions and mounting:

Oval flange body with two mounting holes on the long axis, either side of the bearing bore. The flange face bolts to a plate and locates the shaft perpendicular to the mounting surface. The insert lifts out of the housing; replacement insert: RHP 1000G series.

Compatibility and replacement:

Insert: RHP 1000G series. The four-bolt square-flange counterpart on the same insert is the RHP SF series. MPN Variants: SFT1-9/16, SFT 1-9/16, SFT-1-9/16, SFT1.9/16, SFT1 9/16.

Frequently asked questions:

What housing style is the RHP SFT1-9/16?

A cast iron two-bolt oval flange with two mounting holes either side of the bore.

What shaft size does the SFT1-9/16 take?

1-9/16 in (39.6875 mm), locked with two knurled cup-point set screws.

What temperature range does the SFT1-9/16 run in?

−20 to +110 °C on the standard mineral oil / lithium soap grease.
