Availability:
1 in stock
Inch tapered roller bearing cup, 8.5000 in outside diameter, 1.8750 in width, e factor 0.49. Runs against a 74537 or 74472 cone.
List Price
$283.03
1 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | Timken |
|---|---|
| MPN | 74853 |
| GTIN | 053893396576 |
| Model | 74853 20629 |
| Bearing Type | Tapered Roller Bearing Cup, Open |
| OD | 8.5000 in (215.900 mm) |
| Width | 1.875 in |
| Material | Case Carburized Steel |
|---|---|
| Series | 748 |
| Base Number | 74853 |
| Overall Width | 1.8750 in (47.625 mm) |
| Mpn Variants | 74853; 74-853; 74 853 |
| Compatible With Replaces | Mating cones: Timken 74537, Timken 74472, Timken 74473X |
| Precision Class | Not specified |
| Additional Attributes | e Factor 0.49; Y Factor 1.23; Cg 0.134; Max housing fillet radius 3.30 mm; Da 210.80 mm; Db 196.09 mm |
| Rolling Elements | Tapered Roller |
| Item Weight | 6.60 kg (14.60 lb) |
| Number Of Rows | 1 |
| Harmonization Code | 8482.20.00 |
| Part Number | 74853 |
| Cross Reference 1 | Koyo 74853 |
|---|---|
| Cross Reference 2 | NTN 4T-74853 |
| Cross Reference 3 | NSK 74853 |
| Cross Reference 4 | SKF 74853 |
| Cross Reference 5 | BCA / Bower 74853 |
Timken 74853 inch tapered roller bearing cup. Bearing Type: Tapered roller bearing cup — the outer race of a single-row tapered roller bearing. Series: 748. Base Number: 74853. Outside Diameter: 8.5000 in (215.900 mm). Overall Width: 1.8750 in (47.625 mm). Rolling Elements: Tapered Roller. Number Of Rows: 1. Item Weight: 6.60 kg (14.60 lb). GTIN: 053893396576.
74853 — Timken base cup number in the 748 inch series, 8.5000 in outside diameter. No precision suffix is present, so the tolerance class is Not specified.
e Factor: 0.49. Y Factor: 1.23. Geometry Factor (Cg): 0.134. The e factor is the thrust-to-radial load ratio at which the bearing changes to its thrust-loaded rating equations; the Y factor converts thrust into equivalent radial load in that calculation. An e of 0.49 puts this cup in Timken’s medium-angle group, balanced between radial capacity and thrust capacity.
Maximum fillet radius on the mating housing: 3.30 mm (0.130 in). Housing Backing Shoulder Diameter, frontface (Da): 210.80 mm (8.30 in). Housing Backing Shoulder Diameter, backface (Db): 196.09 mm (7.72 in).
Unit Quantity: 1 Pc. Cup only. Matching cones are the Timken 74537, 74472 and 74473X.
74853 is an industry-standard inch tapered roller bearing cup number. Koyo, NTN, NSK, SKF and BCA/Bower all build a 74853 to the same boundary dimensions as this cup.
