SKF22220-CC/C3W33Double Row Spherical Roller Bearing 100 x 180 x 46 mm, Cylindrical Bore, W33 Lube Groove, Pressed Steel Cage, C3

Product Description

What this part is

A double-row spherical roller bearing with a cylindrical bore, 100 mm bore × 180 mm outside diameter × 46 mm width. Two rows of barrel-profile rollers run on a common spherical outer raceway, so the inner ring and roller set swivel within the outer ring. The bearing carries heavy radial load, takes thrust in both axial directions, and accommodates static misalignment and running shaft deflection.

Decoding the designation

222 — double-row spherical roller dimension series.
20 — bore code, 100 mm.
CC — pressed steel window cage with an inner-ring guide.
C3 — radial internal clearance greater than normal.
W33 — lubrication groove around the outer ring with three radial lubrication holes.
No K suffix — cylindrical bore.

What these specs mean in practice

The spherical outer raceway is what makes the bearing self-aligning, and the double row is what gives it thrust capacity in both directions rather than one. A pressed steel CC cage is the standard execution: light, well proven, and rated for the speeds and temperatures of general industrial service, where a machined brass cage is reserved for higher temperature and heavier shock. The W33 groove and three holes feed lubricant to the centre of the two roller rows from a housing port, which is the arrangement used where the bearing is relubricated on a schedule rather than packed once. C3 clearance leaves running room for a press fit on the shaft, a temperature difference across the bearing, or both, and is the usual choice where the inner ring runs hotter than the housing.

Published ratings and mounting data

Bore: 100 mm (3.937 in), cylindrical
Outside diameter: 180 mm (7.087 in)
Width: 46 mm (1.811 in)
Basic dynamic radial load rating C: 433 kN
Basic static radial load rating C0: 490 kN
Rows: 2
Rolling element: spherical (barrel profile) rollers
Cage: pressed steel, window type
Radial internal clearance: C3, greater than normal
Lubrication feature: W33, outer-ring groove and three radial holes
Closure: open, both faces
Axial load capacity: both directions

Quantity and configuration

Sale unit 1 Pc. Bearing only.

Fitting notes

The cylindrical bore seats directly on the shaft, the interference set by the shaft tolerance rather than by drive-up. Where the W33 holes are used, the housing lube port aligns with the groove, which is continuous around the ring and so requires no rotational indexing.

Interchange guidance

The ISO base number is 22220. A 22220 CC/C4W33 is the same bearing in a wider clearance class and is a related size rather than an interchange, since clearance class governs mounted preload and running temperature. A 22220 CCK/W33 is a related size too, its 1:12 tapered bore calling for a tapered journal or an adapter sleeve instead of a plain shaft seat. A 22220 with a machined brass cage carries different speed and temperature limits and is a different part.
