Availability:
4 in stock
Spherical roller bearing, 50 mm straight bore, 90 mm OD, 23 mm wide, C3 clearance. D1 lubrication groove and holes in the outer ring for grease or oil feed.
List Price
$49.31
4 in stock
On the Shelf & Ready to Ship
On all orders
No Risk, No Hassle
| MFR / Brand | NTN |
|---|---|
| MPN | 22210CD1C3 |
| Model | 22210 C3 |
| Bearing Type | Spherical Roller Bearing, Open |
| ID | 50 mm |
| OD | 90 mm |
| Width | 23 mm |
| Material | High Carbon Chrome Steel |
|---|---|
| Series | 22200 |
| Lubricant | Grease or oil |
| Base Number | 22210 |
| Mpn Variants | 22210CD1C3, 22210 CD1 C3, 22210C3, 22210CW33C3 |
| Cage Type | Pressed, two-piece |
| Rolling Elements | Spherical Roller |
| Number Of Rows | 2 |
| Bore Type | Straight |
| Internal Clearance | C3 |
| Relubrication Feature | D1 groove and holes in outer ring |
| Harmonization Code | 8482.30.00 |
| Closure Type | Open |
| Cross Reference 1 | SKF 22210 E/C3 - current E design |
|---|---|
| Cross Reference 2 | FAG 22210-E1-C3 - current E design |
| Cross Reference 3 | NSK 22210EAE4C3 - current EA design |
NTN 22210CD1C3 double-row spherical roller bearing with a cylindrical bore, outer-ring lubrication groove and C3 internal clearance. The spherical outer raceway self-aligns under shaft deflection or misalignment. Unit Quantity: 1 Pc.
22210 — NTN spherical roller bearing, 222 series, 50 mm bore.
C — NTN C design: two pressed cages with symmetrical rollers.
D1 — lubrication groove and holes in the outer ring, NTN’s form of the W33 feature, feeding grease or oil to the centre of the roller rows.
C3 — radial internal clearance greater than normal.
Bearing Type: Spherical Roller Bearing. Series: 22200. Base Number: 22210. Number Of Rows: 2. Rolling Elements: Spherical Roller. Bore Type: Straight. Closure Type: Open. Cage Type: Pressed, two-piece. Internal Clearance: C3. Lubricant: grease or oil. Relubrication Feature: D1 groove and holes in outer ring. Unit Quantity: 1 Pc. Harmonization Code: 8482.30.00. Country of Origin: Japan.
Bore Diameter: 50 mm. Outside Diameter: 90 mm. Overall Width: 23 mm.
SKF 22210 E/C3 — current E design. FAG 22210-E1-C3 — current E design. NSK 22210EAE4C3 — current EA design. All are 50 x 90 x 23 mm with straight bore, lubrication groove and C3 clearance; the E and EA executions carry higher ratings than the C design.
50 mm bore, 90 mm outside diameter, 23 mm width.
C3, radial internal clearance greater than normal.
A lubrication groove and holes in the outer ring, taking grease or oil.
$44.26
14 in stock
