IKO NAST40ZZ separable roller follower, 40 mm bore, 80 mm OD, 26 mm wide, shields both sides, 35,900 N dynamic rating. Yoke type track roller.
List Price
$37.39
5 in stock
On the Shelf & Ready to Ship
Ships same day by 6pm ET
No Risk, No Hassle
| MFR / Brand | IKO |
|---|---|
| MPN | NAST40ZZ |
| Model | NAST 40 ZZ |
| Bearing Type | Needle Roller Bearing, Shields both sides |
| ID | 40 mm |
| OD | 80 mm |
| Width | 26 mm |
| Series | NAST |
|---|---|
| Dynamic Load Rating | 35,900 N |
| Static Load Rating | 61,100 N |
| Rolling Elements | Needle Roller |
| Item Weight | 0.71 kg (1.57 lb) |
| Number Of Rows | 1 |
| Bore Type | Straight |
| Harmonization Code | 8482.50.00 |
| Industry Terms | roller follower, yoke type track roller, cam roller |
| Common Misspellings | NAST40 Z, NAS T40ZZ, NAST4OZZ |
| Application Types | cam mechanisms, conveyor track rollers, linear guide rollers |
| Mpn Variants | NAST40ZZ, NAST 40 ZZ, NAST40-ZZ, NAST 40ZZ |
| Closure Type | Shields both sides |
The IKO NAST40ZZ is a separable roller follower: a thick-walled outer ring running on a caged complement of needle rollers, with an inner ring, fitted with shields on both sides. It is a yoke type track roller with a 40 mm bore. Each piece is a complete roller follower: outer ring, caged needle rollers, inner ring and shields. Unit Quantity: 1 Pc.
NAST — IKO separable roller follower with cage and inner ring, cylindrical outer ring.
40 — 40 mm bore.
ZZ — shields on both sides.
Bearing Type: Yoke Type Track Roller. Rolling Elements: Needle Roller. Number Of Rows: 1. Closure Type: Shields both sides. Series: NAST. Dynamic Load Rating: 35,900 N. Static Load Rating: 61,100 N.
Bore Diameter: 40 mm. Outside Diameter: 80 mm. Overall Width: 26 mm. Item Weight: 0.71 kg (1.57 lb).
The NAST40ZZ is IKO’s shielded execution. The plain NAST40 is a separate part number: 20 mm wide, 0.53 kg, same bore and outside diameter.
Bore Diameter: 40 mm. Outside Diameter: 80 mm. Overall Width: 26 mm.
Dynamic Load Rating: 35,900 N. Static Load Rating: 61,100 N.
ZZ marks shields on both sides of the roller follower.
